2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric
2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric
2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric
2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric
2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric
2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric
2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric
2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric
Specifications
Brand Name :
YEAWEY
Model Number :
CQD20BS
Certification :
CE ISO，SGS
Place of Origin :
China
MOQ :
1 unit
Price :
6000-7500 usd
Payment Terms :
L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :
100 units per month
Delivery Time :
5-8 working days
Packaging Details :
Plastic bag
Product name :
2T Electric Reach stacker 24V seat type
Load capacity :
2T
Lift height :
3-6m
Mast type :
Triplex mast
Battery :
48V/400Ah
Service weight :
2535 kgs
Description

2000kg 48V CQD20BS 2.0T Electric Reach forklift truck stand type triplex 3-9m mast

Main information:

Curtis AC controller

AC lift and drive motor

Lift height 3m to 6m

Lead acid battery 24V/2810AH

Stand type

The YEAWEY Lead acid / Lithium battery stand reach truck adopts four columns for cabin to penetrate the frame which is both beautiful and safe.Wide field of vision and driving space along with high elastic shock-absorbing seats provide a unique driving pleasure.

Multi-function LCD instrument

Multi-function LCD instrument can display steering wheel position, battery power, power alarm, fault code running time, driving speed and other information.

Humanized design

Wide vision and driving space,ergonomic layout,embodies the humanized design.

Stable operation

Elector-hydraulic proportional control system, good fretting performance, more stable work and more precise control.

Spacious foot space

Spacious foot space allows any operator to find a comfortable position and ensures adequate comfort during operation throughout the shift.

Item Model CQD20-45S
1 Power type Electric
2 Drive mode Standing Type
3 Load capacity Q(kg) 2000
4 Load center C(mm) 500
5 Wheel base Y(mm) 1533
6 Reach distance L(mm) 594
7 Self weight with battery kg 3025
8 Tire type Pu solid tire
9 Front tire size ∅×w(mm) 267*114
10 Rear tire size ∅×w(mm) 382*142
11 Balance wheel size ∅×w(mm) 180*76
12 Track width, front wheels b10(mm) 1081
13 Height-Mast lowered h1(mm) 2100
14 Free Lift Height h2(mm) 1500
15 Lift Height h3(mm) 4500
16 The maximum height of the gantry during homework h4(mm) 5480
17 The height of overhead guards h14(mm) 2305
18 The height when fork lowered h13(mm) 40
19 Tilt-Forward/Back α/β(°) 3/5
20 Overall length without forks/with forks l2(mm) 1902/2405
21 Width of the body b1(mm) 1195
22 Fork Dimensions s/e/l(mm) 40/122/1070
23 Fork Spread b5(mm) 244-700
24 Min ground clearance m2(mm) 80
25 Aisle Width,pallet 1000*1200mm Ast(mm) 2882
26 Min. Turning radius Wa(mm) 1836
27 Max.walking speed km/h 8/7
28 Max. lifting speed m/s 0.300/0.235
29 Max. lowing speed m/s 0.330/0.400
30 Grade Ability ％ ≤10
31 Drive brake electromagnetic
32 Drive motor kw 6.5
33 Lift motor kw 6.3
34 Battery type Lead acid
35 Battery capacity V/Ah 48V400Ah
36 Charger V/Ah 48V/50A
37 DriveControllingType alternating current
38 The noise level in the driver's ear according to EN12053 dB(A) 75

2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric

2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric



2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric

2000kg 48V CQD20BS 2.0T Electric Reach Forklift Stand Type Reach Truck Electric
