20kW Axial Flux Direct Drive Permanent Magnet Generator 380V 200rpm Low Speed
20kW Axial Flux Direct Drive Permanent Magnet Generator 380V 200rpm Low Speed
20kW Axial Flux Direct Drive Permanent Magnet Generator 380V 200rpm Low Speed
20kW Axial Flux Direct Drive Permanent Magnet Generator 380V 200rpm Low Speed
20kW Axial Flux Direct Drive Permanent Magnet Generator 380V 200rpm Low Speed
20kW Axial Flux Direct Drive Permanent Magnet Generator 380V 200rpm Low Speed
20kW Axial Flux Direct Drive Permanent Magnet Generator 380V 200rpm Low Speed
20kW Axial Flux Direct Drive Permanent Magnet Generator 380V 200rpm Low Speed
Specifications
Payment Terms :
L/C,T/T,Western Union
Delivery Time :
15-45 Days after Deposit
Rated Speed :
200rpm
Protection Grade :
IP54
Cooling Method :
Natural Cooled
Frequency :
50Hz / 60Hz
Certification :
CE, ISO 9001:2015
MOQ :
1 Set
Number of Poles :
30
Price :
USD 500-5,000 / Set
Model Number :
ECER-AF-20
Supply Ability :
20000 Sets per Year
Brand Name :
ECER
Phase :
Three Phase
Flux Type :
Axial Flux
Rated Power :
20kW
Place of Origin :
China
Magnet Material :
NdFeB Neodymium
Packaging Details :
Seaworthy plywood wooden case with foam shock-proof lining
Rated Voltage :
380V AC
Efficiency :
96%
Application :
Small Wind / Low Head Hydro
Description

20kW Axial Flux Direct Drive Permanent Magnet Generator 380V 200rpm Low Speed

20kW Axial Flux Direct Drive Permanent Magnet Generator 380V 200rpm Low Speed

This 20kW axial flux direct drive permanent magnet generator uses a pancake style rotor to deliver high torque at just 200rpm without a gearbox. The gearless construction removes mechanical loss and wear, making this permanent magnetic generator the reliable heart of small wind turbines and low-head hydro systems.

Key Features

  • Axial flux pancake design delivers high torque density in a short axial length
  • Direct drive gearless operation at 200rpm low speed with no gearbox loss
  • NdFeB neodymium magnets for stable generation from variable renewable input
  • 96% efficiency across the operating speed range
  • IP54 protection for outdoor turbine and generator house installation

Technical Specifications

Rated Power20kW
Rated Voltage380V AC
PhaseThree Phase
Frequency50Hz / 60Hz
Rated Speed200rpm
Flux TypeAxial Flux
Number of Poles30
Efficiency96%
Cooling MethodNatural Cooled
Magnet MaterialNdFeB Neodymium
Protection GradeIP54
ApplicationSmall Wind / Low Head Hydro

Structure & Design

20kW Axial Flux Direct Drive Permanent Magnet Generator 380V 200rpm Low Speed

Rotor and stator assemblies are manufactured with CNC precision and balanced to low vibration grades. The generator housing is available in foot-mounted or flange-mounted versions to match the turbine or engine drivetrain.

Applications

20kW Axial Flux Direct Drive Permanent Magnet Generator 380V 200rpm Low Speed

Designed for 5-25kW small wind turbines, low-head hydro turbines and tidal current generators where low speed direct drive generation is required.

Quality & Warranty

CE and ISO9001 certified with full factory test report and 3-year warranty. OEM/ODM customization is available for voltage, frequency, speed and shaft dimensions.

ECER is an experienced permanent magnet generator manufacturer. Contact our sales team for quotation and technical support.
