Specifications
Certification :
CE, ISO 9001
Pole Number :
4 Poles
Mounting Type :
B35 (B3/B5 Optional)
Packaging Details :
Export plywood case with foam protection
Brand Name :
ECER
Rated Voltage :
380V
Place of Origin :
China
MOQ :
1 Piece
Noise Level :
<=70dB(A)
Supply Ability :
100 Sets per Month
Price :
USD 1000-1900 / Piece
Speed Range :
100-3000RPM
Delivery Time :
15-30 working days
Protection Class :
IP55
Magnet Type :
NdFeB Rare Earth
Insulation Class :
Class H
Cooling Method :
IC411 Self Fan Cooled
Rated Power :
11KW
Payment Terms :
T/T,L/C,Western Union
Frequency :
50Hz Base, 5-100Hz Range
Model Number :
ECER-VF-11
Efficiency Class :
IE5 Ultra Premium
Description
11KW VFD Variable Speed Permanent Magnet Motor Wide Range for Pump Fan Duty
Product Overview

This 11KW Permanent Magnet Motor is optimized for variable frequency drive operation across a wide speed range. Unlike induction motors that lose efficiency away from base speed, this Permanent Magnetic Motor maintains high efficiency from low speed up to rated speed, making it the preferred choice for flow and pressure control in pump and fan systems.

Fig.1 11KW Permanent Magnet Motor Structure Diagram
Key Features
  • VFD compatible winding and insulation for inverter duty
  • Wide speed range with stable torque from low speed to rated speed
  • High efficiency maintained across the whole speed range
  • Soft start capability removes mechanical shock from the driveline
  • Typical energy saving of 20-30% on centrifugal loads
Technical Specifications
Rated Power 11KW
Rated Voltage 380V
Frequency 50Hz Base, 5-100Hz Range
Efficiency Class IE5 Ultra Premium
Speed Range 100-3000RPM
Pole Number 4 Poles
Protection Class IP55
Cooling Method IC411 Self Fan Cooled
Insulation Class Class H
Mounting Type B35 (B3/B5 Optional)
Magnet Type NdFeB Rare Earth
Noise Level <=70dB(A)
Applications

Suited to variable speed pumps, fans, blowers, HVAC units and compressors, where a VFD driven Permanent Magnet Motor matches output to demand and minimizes electricity consumption.

Fig.2 11KW Permanent Magnetic Motor Industrial Application
Quality Assurance

Every inverter duty Permanent Magnetic Motor is surge tested and run in with a VFD before delivery, under ISO9001 quality control, with an 18-month warranty.

Model ECER-VF-11

Available for worldwide export. Contact us for VFD selection support, drawings and pricing details.
