1500kW IP67 Water Cooled Permanent Magnet Generator for Offshore Wind Direct Drive Wind PMSG
1500kW IP67 Water Cooled Permanent Magnet Generator for Offshore Wind Direct Drive Wind PMSG
1500kW IP67 Water Cooled Permanent Magnet Generator for Offshore Wind Direct Drive Wind PMSG
1500kW IP67 Water Cooled Permanent Magnet Generator for Offshore Wind Direct Drive Wind PMSG
1500kW IP67 Water Cooled Permanent Magnet Generator for Offshore Wind Direct Drive Wind PMSG
1500kW IP67 Water Cooled Permanent Magnet Generator for Offshore Wind Direct Drive Wind PMSG
1500kW IP67 Water Cooled Permanent Magnet Generator for Offshore Wind Direct Drive Wind PMSG
1500kW IP67 Water Cooled Permanent Magnet Generator for Offshore Wind Direct Drive Wind PMSG
1500kW IP67 Water Cooled Permanent Magnet Generator for Offshore Wind Direct Drive Wind PMSG
1500kW IP67 Water Cooled Permanent Magnet Generator for Offshore Wind Direct Drive Wind PMSG
Specifications
Speed Range :
5rpm to 17rpm
Model Number :
EPMG-1500DD
Cooling Method :
Water Cooled
Payment Terms :
T/T,L/C
Packaging Details :
Steel frame + waterproof plywood case, seaworthy export packing with lifting lugs
Bearing Brand :
SKF
Protection Grade :
IP67
Efficiency :
>=96%
Price :
USD 90000-160000 / set
Rated Voltage :
690V AC
Insulation Class :
Class H
Rated Power :
1500kW
Supply Ability :
50 sets per year
Delivery Time :
15-30 working days for stock models, 60-120 days for large or custom units
Frequency :
Converter to 50/60Hz
Poles :
120
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Phase :
Three Phase
Rated Speed :
15rpm
Brand Name :
ENNENG
Description
1500kW Direct Drive Permanent Magnet Generator PMSG 690V for Offshore Wind
This 1500kW direct drive permanent magnet generator is engineered for offshore and large onshore wind turbines. The 120-pole rotor operates at only 15rpm together with the hub, completely eliminating the gearbox and reducing the main shaft drive train from three heavy components down to one slow-speed electric machine.
Key Features
  • Gearbox-free drive train reduces tower head mass and maintenance costs offshore
  • 120-pole low-speed rotor with high torque density for 15rpm direct coupling
  • Sealed IP67 enclosure with marine-grade corrosion protection for offshore salt atmosphere
  • Water-cooled stator with redundant cooling loops for continuous full load operation
  • Converter-interfaced variable speed operation from 5rpm to 17rpm
Technical Parameters
Name 1500kW Direct Drive Wind PMSG
Rated Power 1500kW
Rated Voltage 690V AC
Phase Three Phase
Frequency Converter to 50/60Hz
Rated Speed 15rpm
Poles 120
Efficiency ≥96%
Protection Grade IP67
Insulation Class Class H
Cooling Method Water Cooled
Bearing Brand SKF
Structure Diagram

1500kW IP67 Water Cooled Permanent Magnet Generator for Offshore Wind Direct Drive Wind PMSG

Applications

Developed for 1.5MW class offshore wind turbines and large distributed wind farms. Drive train engineering service, cooling system sizing, and converter matching are offered with each unit.

Application

1500kW IP67 Water Cooled Permanent Magnet Generator for Offshore Wind Direct Drive Wind PMSG

Quality and Service

Every unit is load tested before shipment and supplied with test certificate, wiring diagram, and installation manual. CE certification and OEM service are available. Please contact our engineers with your turbine or genset parameters to confirm the matching permanent magnet generator solution.
