Specifications
Certification :
CE
Poles :
4
Efficiency :
>=94%
Frequency :
50Hz / 60Hz
Phase :
Three Phase
Overload Capability :
High
Insulation Class :
Class H
Place of Origin :
China
Rated Power :
140kW
Rated Speed :
1500rpm / 1800rpm
Price :
USD 9000-15000 / set
Supply Ability :
600 sets per year
Packaging Details :
Steel frame + waterproof plywood case, seaworthy export packing with lifting lugs
Brand Name :
ENNENG
Rated Voltage :
400V AC
Protection Grade :
IP23
Model Number :
EPMG-140QN
Payment Terms :
T/T,L/C
Cooling Method :
Air Cooled
MOQ :
1 Set
Delivery Time :
15-30 working days for stock models, 60-120 days for large or custom units
Noise Level :
<75dB(A)
Description
140kW Low Noise Permanent Magnet Generator 400V 1500rpm for Genset PMSG
This 140kW low noise permanent magnet generator is a four pole PMG alternator running at 1500rpm for 50Hz standby and prime power gensets. Without excitation winding and slip rings the alternator runs quieter and cooler, which helps the complete genset meet strict residential and hospital noise limits.
Key Features
  • Noise level below 75dB(A) at 1m, suitable for noise sensitive sites
  • No excitation system, AVR or slip ring, reducing failure points of the set
  • Fast voltage response and high overload capability for motor starting loads
  • Balanced three phase 400V output with low harmonic distortion
  • Compact 4 pole frame easy to couple with standard diesel engine bell housing
Technical Parameters
Name 140kW Low Noise Genset PMG
Rated Power 140kW
Rated Voltage 400V AC
Phase Three Phase
Frequency 50Hz / 60Hz
Rated Speed 1500rpm / 1800rpm
Poles 4
Efficiency >=94%
Noise Level <75dB(A)
Protection Grade IP23
Insulation Class Class H
Cooling Method Air Cooled
Structure Diagram

140kW Low Noise 400V Permanent Magnet Generator for Genset PMSG

Applications
  • 140kVA class standby gensets
  • Telecom base station power
  • Hospital backup systems
  • Prime power rental fleets
60Hz 1800rpm version is available.
Application

140kW Low Noise 400V Permanent Magnet Generator for Genset PMSG

Quality and Service
Every unit is load tested before shipment and supplied with test certificate, wiring diagram and installation manual. CE certification and OEM service are available. Please contact our engineers with your turbine or genset parameters to confirm the matching permanent magnet generator solution.
