350kW Water Cooled Permanent Magnet Generator 690V for Hydro Turbine Applications
350kW Water Cooled Permanent Magnet Generator 690V for Hydro Turbine Applications
350kW Water Cooled Permanent Magnet Generator 690V for Hydro Turbine Applications
350kW Water Cooled Permanent Magnet Generator 690V for Hydro Turbine Applications
350kW Water Cooled Permanent Magnet Generator 690V for Hydro Turbine Applications
350kW Water Cooled Permanent Magnet Generator 690V for Hydro Turbine Applications
350kW Water Cooled Permanent Magnet Generator 690V for Hydro Turbine Applications
350kW Water Cooled Permanent Magnet Generator 690V for Hydro Turbine Applications
350kW Water Cooled Permanent Magnet Generator 690V for Hydro Turbine Applications
350kW Water Cooled Permanent Magnet Generator 690V for Hydro Turbine Applications
Specifications
Supply Ability :
200 sets per year
Model Number :
EPMG-350WC
Certification :
CE
Phase :
Three Phase
Poles :
8
Protection Grade :
IP54
Rated Speed :
750rpm / 900rpm
MOQ :
1 Set
Name :
350kW Water Cooled Hydro PMSG
Cooling Method :
Water Cooled
Packaging Details :
Steel frame + waterproof plywood case, seaworthy export packing with lifting lugs
Rated Voltage :
690V AC
Delivery Time :
15-30 working days for stock models, 60-120 days for large or custom units
Rated Power :
350kW
Efficiency :
>=95%
Bearing Brand :
SKF
Winding Material :
100% copper
Brand Name :
ENNENG
Payment Terms :
T/T,L/C
Insulation Class :
Class H
Place of Origin :
China
Price :
USD 20000-35000 / set
Frequency :
50Hz / 60Hz
Description
350kW Water Cooled Permanent Magnet Generator 690V 750rpm for Hydro Turbine

This 350kW water cooled permanent magnet generator delivers high efficiency for medium scale hydro stations where compact dimensions are required. Water jacket cooling removes heat more effectively than air, allowing a smaller frame for the same rating and keeping winding temperature rise low even in tropical powerhouse environments.

Key Features
  • Water jacket cooling keeps temperature rise low and efficiency above 95%
  • 100% copper winding with vacuum pressure impregnation for moisture resistance
  • NdFeB magnets with anti demagnetization coating for 20 year rotor life
  • SKF bearings with replaceable cartridge design simplify site maintenance
  • 690V output reduces step up transformer ratio and cable losses
Technical Parameters
Name 350kW Water Cooled Hydro PMSG
Rated Power 350kW
Rated Voltage 690V AC
Phase Three Phase
Frequency 50Hz / 60Hz
Rated Speed 750rpm / 900rpm
Poles 8
Efficiency >=95%
Protection Grade IP54
Insulation Class Class H
Cooling Method Water Cooled
Bearing Brand SKF
Structure Diagram

350kW Water Cooled Permanent Magnet Generator 690V for Hydro Turbine Applications

Applications

Applied in 300-400kW class hydro stations, industrial self power plants and water supply pressure reduction energy recovery units. Cooling water flow requirement and heat exchanger options provided with the datasheet.

Application

350kW Water Cooled Permanent Magnet Generator 690V for Hydro Turbine Applications

Quality and Service

Every unit is load tested before shipment and supplied with test certificate, wiring diagram and installation manual. CE certification and OEM service are available. Please contact our engineers with your turbine or genset parameters to confirm the matching permanent magnet generator solution.
