Custom Insert Molds H13 Steel Plastic Injection Moulding Tooling 700K - 1.3M Cycles
Custom Insert Molds H13 Steel Plastic Injection Moulding Tooling 700K - 1.3M Cycles
Specifications
Brand Name :
MID MOULD
Place of Origin :
Dongguan, China
MOQ :
1 set
Payment Terms :
50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
Delivery Time :
25–45 working days (longer for complex tools)
Certification :
ISO9001,FDA,ISO13485
Price :
USD $3,000–$50,000 per set (depending on complexity)
Packaging Details :
Wooden case + anti-rust oil + protective film + packing list
Supply Ability :
20–35 sets per month, depending on structure
Product name :
Insert Molds
Shaping mode :
Plastic Injection Mould,Plastic injection molding,Compression Mould
Material :
STEEL,ps,PP,Steel and metal,aluminum
Product :
Vehicle Mould,Household Appliance,plastic injection mold,injection machine mold,Household Product
Mould life :
250000-300000shots,200~1 M available,300,000shots,000 times
Runner :
Hot Runner\ Cold Runner,cold/hot
Cavity :
Multi Cavity,as per client's requirement
Product material :
Plastic,Steel,PP,ABS,PS
Mold material :
NAK80,H13,50#,P20,45#
Design software :
CAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
Mould material :
P20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 etc,H13
Application :
Home Appliance,Industrial,Automotive,various range,Machine
Mould base :
non-Standard plastic injection mould,World standard,European standard,LKM.HASCO,HASCO standard
Surface treatment :
sandblasted,Texture,anodizing black,clear painting,Polishing
Size :
as samples/drawings,customized accepted,Customized Size
Mold runner :
Hot&Cold runner you can choose,Hot runner and code runner
Mold life :
000 to 1,500000 shots,000 shots,100000-1000000,50
Plastic material :
Peek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
Description
Product Process

Insert injection molding improves the overall performance and practicality of a product by embedding functional components into the plastic during the injection molding process. This process reduces assembly steps, improves production efficiency, and ensures consistent appearance and precision.

Process Flow
  • Mold Design: Analysis of Insert Positioning and Stress Distribution
  • CAE Simulation: Optimization of Filling and Venting Design
  • Precision Machining: CNC and EDM Complete Cavity Fabrication
  • Assembly of Cooling System and Insert Positioning Device
  • Mold Trial Testing: Verification of Bonding Strength and Dimensions
Product Specifications
Item Parameter Description
Mold Type Insert Injection Mold
Mold Material H13, S136, P20
Number of Cavities 2–12
Mold Life 700,000–1.3 Million Cycles
Surface Treatment Mirror Polishing, Sandblasting, Nitriding
Applicable Plastics PA66, PBT, ABS, PC
Insert Type Copper, Steel, Nut
Product Accuracy ±0.015mm
Cooling System Multi-Circuit Water Cooling System
Production Cycle 50–80 Days
Product Advantages
  • One-Shot Molding, Reduces Assembly Steps
  • High Accuracy: ±0.015mm
  • Long Mold Life, Controllable Costs
  • Strong Bonding, Durable
FAQ
  • Q1: Can the Mold Withstand High-Intensity Production?

    A1: Yes, with a service life of up to one million mold cycles.

  • Q2: Will the part deform?

    A2: Mold flow analysis and cooling systems ensure stability.

  • Q3: Can complex inserts be made?

    A3: Yes, we support multiple insert combinations.

  • Q4: What is the production cycle?

    A4: Typically 50–80 days.

  • Q5: Can customization be provided?

    A5: Yes, we can customize the design based on customer needs.

Customized Services

We support customized solutions for mold cavity count, insert type, cooling system, and surface treatment to ensure our customers' production goals are met.
