Insert Molds Medical Grade Plastic Injection with Embedded Metal Components for High Precision Devices
Insert Molds Medical Grade Plastic Injection with Embedded Metal Components for High Precision Devices
Insert Molds Medical Grade Plastic Injection with Embedded Metal Components for High Precision Devices
Insert Molds Medical Grade Plastic Injection with Embedded Metal Components for High Precision Devices
Specifications
Brand Name :
MID MOULD
Place of Origin :
Dongguan, China
MOQ :
1 set
Payment Terms :
50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
Delivery Time :
25–45 working days (longer for complex tools)
Certification :
ISO9001,FDA,ISO13485
Price :
USD $3,000–$50,000 per set (depending on complexity)
Packaging Details :
Wooden case + anti-rust oil + protective film + packing list
Supply Ability :
20–35 sets per month, depending on structure
Shaping mode :
Plastic Injection Mould,Plastic injection molding,Compression Mould
Material :
STEEL,ps,PP,Steel and metal,aluminum
Product :
Vehicle Mould,Household Appliance,plastic injection mold,injection machine mold,Household Product
Mould life :
250000-300000shots,200~1 M available,300,000shots,000 times
Runner :
Hot Runner\ Cold Runner,cold/hot
Cavity :
Multi Cavity,as per client's requirement
Product material :
Plastic,Steel,PP,ABS,PS
Mold material :
NAK80,H13,50#,P20,45#
Design software :
CAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
Mould material :
P20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 etc,H13
Application :
Home Appliance,Industrial,Automotive,various range,Machine
Product name :
Plastic Injection Mould,injection machine mold,Shanghai Factory Cheap Plastic Component Injection Mold,High quality virgin raw material custom plastic injection mold product,Gear parts
Mould base :
non-Standard plastic injection mould,World standard,European standard,LKM.HASCO,HASCO standard
Surface treatment :
sandblasted,Texture,anodizing black,clear painting,Polishing
Size :
as samples/drawings,customized accepted,Customized Size
Mold runner :
Hot&Cold runner you can choose,Hot runner and code runner
Mold life :
000 to 1,500000 shots,000 shots,100000-1000000,50
Plastic material :
Peek,ABS/PP/PS/PE/PVC/PA6/PA66..et,MC Nylon,Derlin,UHMW-PE
Description
Product Process

Insert molds encase metal needles or structural components within plastic parts in a single molding process. Suitable for the medical industry, which demands extremely high precision and safety.

Process Flow
  1. Requirements Analysis and Product Safety Design
  2. CAD/CAE Melt Flow Simulation
  3. High-Precision CNC Machining Cavity
  4. Assembly Positioning and Cooling System
  5. Mold Trial Verification for Medical Standards
Product Specifications
Item Parameter Description
Mold TypeInsert Injection Mold
Mold MaterialS136 H13
Number of Cavities1–8
Mold Life600,000–1,000,000 Molds
Surface TreatmentPolished, Mirror Finish
Applicable MaterialsPP, ABS, PC
Insert TypeMetal Syringes, Medical Parts
Product Accuracy±0.01mm
Cooling SystemIndependent Water Cooling System
Production Cycle50–70 Days
Product Applications
  • Medical Syringes
  • Infusion Set Components
  • Medical Testing Instrument Accessories
Product Advantages
  • High Precision, Meets Medical Standards
  • Integrated Molding, Hygienic and Safe
  • Improves Production Efficiency
FAQ
Q1: Does it Meet Medical Standards?
A1: Yes, Made of Food-Grade and Medical-Grade Steel
Q2: Is the Mold Suitable for Transparent Parts?
A2: This can be achieved through mirror polishing.
Q3: What is the service life?
A3: Over a million molds.
Q4: Does it support small-batch verification?
A4: We can provide trial mold services.
Customized Services

We can design and manufacture insert molds that meet medical standards, ensuring product safety and precision.
