200 Tons PET Bottle Preform Vertical Injection Machine 150 Grams PVC Sole Machine
200 Tons PET Bottle Preform Vertical Injection Machine 150 Grams PVC Sole Machine
200 Tons PET Bottle Preform Vertical Injection Machine 150 Grams PVC Sole Machine
200 Tons PET Bottle Preform Vertical Injection Machine 150 Grams PVC Sole Machine
200 Tons PET Bottle Preform Vertical Injection Machine 150 Grams PVC Sole Machine
200 Tons PET Bottle Preform Vertical Injection Machine 150 Grams PVC Sole Machine
200 Tons PET Bottle Preform Vertical Injection Machine 150 Grams PVC Sole Machine
200 Tons PET Bottle Preform Vertical Injection Machine 150 Grams PVC Sole Machine
Specifications
Brand Name :
LIZHU
Model Number :
LZ-LB
Certification :
CE, CSA
Place of Origin :
CHINA
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
10 pcs/month
Delivery Time :
7-10days
Packaging Details :
Carton packing
Name :
Vertical Preform Injection Molding Machine
Clamping Force :
200 tons
Injection Weight :
150 grams
Injection Speed :
500 mm/s
Injection Rate :
300g/s ~ 1200g/s
Warranty :
12 months
Description

Pet Preform Vertical Injection Molding Machine

1. Description:

2. A vertical clamping and injection design that is particularly suited to the manufacture of insert molding.

3. Uses parts from international brands to maintain machine accuracy, stability, and dependability.

4. A high-power motor guarantees plasticizing capacity when it is operating.

5. A multilingual, user-friendly LCD display that displays different functions and working conditions.

2. Sepcifications:

Item Unit LZ-LB
Injection Unit Screw Diameter mm Ø35 Ø40 Ø45
Injection Pressure Kg/cm2 2200 1835 1208
Theoretical Shot Volume cm3 214 251 312
Shot Weight(PS) g 178 219 236
oz 6.2 7.5 9.3
Injection Rate cm3/sec 170 222 265
Screw Stroke mm 160
Screw Rate rpm 0-250
Injection speed mm/s 134
Nozzle Stroke mm 360
Clamping Force Clamping Force tons 200
Opening Force tons 20
Sliding Plate Size mm 570*560
Plate Size mm 585*1130
Rotary Table Diameter mm Ø1300
Sliding Table Stroke mm -
Max Mold Size mm 560*345
Min Mold Thickness mm 300(50+50)
Opening Stroke mm 245
Max Opening Stroke mm 550(50+50)
Position tolerance mm ±0.03
Ejector Unit Ejector Stroke mm 50/110
Ejector Force Tons 8
Ejector Diameter mm 20
Ejector PCS. pcs 1
Hybrid Unit Oil Tank Volume liters 145
Cold Water Volume Liters/min 170
Servo Motor kw 25
Heating Volume kw 10
Total Wattage kw 35
Others Machine Weight tons 5.8
Machine Size m *****

3. Machine Features:

1. English LCD display with 60 mold data storage
2. A double, three-position turntable with smooth rotation and the ability to accommodate various multi-mode insert processing can significantly increase productivity and save labor costs.
3. The machine is safe, the product withdrawal embedding work does not form a station, and the same task may be performed in the external position.
4.The proportion of dual (pressure, flow)control, the machine running quietly, quickly, and with protection from low pressure

4. Pictures:

200 Tons PET Bottle Preform Vertical Injection Machine 150 Grams PVC Sole Machine

5. FAQ:

1) Are you a manufacturer or a trading company?

We are professional vertical injection molding machine manufacturer in China.

2) Why Choose you?

We have high quality, professional team, good service, and competitive prices.

3) How can you guarantee quality?

Our professional team will give good suggestion and designing before start production, and always final Inspection before shipment.

4) Do you accept my own design?

We can provide OEM/ODM service.

5)How many times can I get my machine after I paid?

If the machine is in stock, the delivery time is usually 3-5 days; if not, it will take 10–25 days, depending on the quantity you need and our busy season.
