24 Channel Electronic Counting Machine 580kg 1760mm Pill Counting Device
24 Channel Electronic Counting Machine 580kg 1760mm Pill Counting Device
Specifications
Model Number :
TW-24
Capacity :
80-100 bottles/minute
Payment Terms :
T/T
Net weight :
580kg
Userinterface :
Touchscreen HMI
Maintenance :
Easy maintenance with modular design
Afrer sale service :
24hours in 7 days online support
Features :
24 Channels Automatic Multi Lanes Counting Machine
Certification :
CE
Power :
1.5kw
Customizationoptions :
Available based on product and packaging requirements
Powersupply :
220V/380V, 50Hz/60Hz
Brand Name :
TIWIN INDUSTRY
Number of channels :
24
Place of Origin :
Shanghai,China
Machine dimension :
1760 x 1650 x 1650 mm
Industry :
Pharmaceutical,food,nutrition
Delivery Time :
20 business days
Description
24-Channel Electronic Counting Machine
Designed for high-speed, large-scale solid dosage packaging lines, this 24-channel automatic electronic counting machine counts and fills all types of tablets, hard capsules, softgels, pills, and custom-shaped solid products into bottles with 100% accuracy. With 24 independent counting lanes and a multi-stage vibratory feeding system, this heavy-duty machine is the ultimate choice for nutraceutical manufacturers looking to maximize throughput while maintaining strict compliance with cGMP and FDA standards.
Technical Specifications
Model TW-24
Suitable Bottle Type Round, square shaped plastic bottle
Suitable for Tablet/Capsule Size 00~5# capsule, soft capsule, with 5.5 to 20 tablets, special-shaped tablets
Production Capacity 80-100 bottles/min
Bottle Setting Range 1-9999
Power Requirements AC220V 50Hz 1.5kw
Accuracy Rate >99.5%
Overall Dimensions 1760 x 1650 x 1650 mm
Weight 580kg
Key Features
  • Ultra-High Throughput The 24-lane configuration allows for massive output, delivering stable and continuous high-speed production to keep up with the fastest capping and labeling machines downstream.
  • Intellectual Dust Compensation Equipped with an upgraded dust-resistant sensor matrix that automatically adjusts detection thresholds, preventing miscounts caused by heavy powder or dust buildup.
  • Multi-Stage Vibratory Separation Uses a 3-stage electromagnetic vibratory plate system to smoothly separate and align products, ensuring single-file entry into the counting channels without causing damage to fragile softgels or tablets.
  • Alternate Dual-Nozzle Filling Features a high-speed pneumatic gating and dual-discharge system that alternate-fills bottles, reducing bottle changeover idle time to near zero.
