220V 380V Tablet Counting Line Automatic Cylindrical Desiccant Inserter Machine
220V 380V Tablet Counting Line Automatic Cylindrical Desiccant Inserter Machine
Specifications
Place of Origin :
Shanghai,China
Desiccant type :
Cylindrical/Column desiccant canister
With conveyor :
Yes
Userinterface :
Touchscreen HMI
Certification :
CE
Maintenance :
Easy maintenance with modular design
Afrer sale service :
24hours in 7 days online support
Brand Name :
TIWIN INDUSTRY
Model Number :
TW-C121
Control :
PLC touch screen
Delivery Time :
20 business days
Customizationoptions :
Available based on product and packaging requirements
Powersupply :
220V/380V, 50Hz/60Hz
MOQ :
1 Set
Packaging Details :
Fumigation-free export-grade plywood case
Supply Ability :
30 Sets per Month
Suitable bottles :
Round, oblate, square, oblate square
Feeding method :
Rotary turntable hole position
Industry :
Pharmaceutical,food,nutrition
Payment Terms :
T/T
Capacity :
60-70 bottles per minute
Description
Automatic Cylindrical Desiccant Insertion Machine TW-C121
TW-C121 Automatic Cylindrical Desiccant Insertion Machine Rotary Turntable 60-70 Bottles Per Min CE
The TW-C121 Automatic Cylindrical Desiccant Insertion Machine is a fully automatic inline station designed to insert column-type desiccant canisters into pharmaceutical, nutraceutical, and health supplement bottles during the packaging process. Using a precision rotary turntable feeding mechanism, the machine picks, orients, and drops one desiccant canister into each bottle passing through the conveyor—ensuring moisture protection for every packaged product.
With a capacity of 60-70 bottles per minute and compatibility with round, oblate, square, and oblate square bottles, the TW-C121 integrates seamlessly between upstream tablet counting/filling machines and downstream capping equipment. The PLC touch screen control with multiple monitoring and alarm functions ensures continuous, unattended operation with automatic fault detection and no-bottle-no-insertion protection.
Technical Specifications
Model TW-C121
Application Automatic cylindrical desiccant canister insertion into bottles
Suitable Bottles Round, oblate, square, oblate square
Desiccant Type Column/Cylindrical desiccant canister
Capacity 60-70 bottles/minute
Voltage & Power AC220V 50Hz 0.5kW
Air Source 0.6 Mpa
Machine Dimensions 1800 * 1350 * 1600 mm
Net Weight 280 kg
Feeding Method Hole position rotary turntable feeding
Control System PLC with touch screen HMI
Key Features
  • Rotary Turntable Feeding: Hole position feeding method picks individual desiccant canisters from the hopper and precisely drops one per bottle cycle.
  • Universal Bottle Compatibility: Handles round, oblate, square, and oblate square bottles of various materials through adjustable guide rails and bottle-stopping cylinder mechanism.
  • Intelligent Monitoring System: No-bottle-no-insertion protection, desiccant level alarm, fault self-check, and missed-insertion detection ensure 100% insertion accuracy.
  • PLC Touch Screen Control: Intuitive interface with production counting, speed adjustment, and alarm history for simplified operation and troubleshooting.
  • Full Line Integration: Automatic joint control with upstream tablet counters/fillers and downstream cappers—no dedicated operator required.
  • Quick Format Changeover: Adjustable bottle guide rails and tool-free desiccant hopper access for rapid change between bottle sizes and desiccant types.
