300gsm 4400mm 350m/Min Wood Pulp Making Machine
300gsm 4400mm 350m/Min Wood Pulp Making Machine
300gsm 4400mm 350m/Min Wood Pulp Making Machine
300gsm 4400mm 350m/Min Wood Pulp Making Machine
Specifications
Brand Name :
HAIYANG
Model Number :
4200MM
Certification :
CE
Place of Origin :
China
MOQ :
1 SET
Price :
USD 0.2-2 million
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20 SETS PER YEAR
Delivery Time :
180 DAYS
Packaging Details :
EXPORT STANDARD PACKAGE
Raw material :
waste paper ,wood pulp
Net paper width :
4400mm
Capacity :
200 T/D
Working speed :
150-350m/min
Gauge :
5400mm
paper weight :
100-300gsm
Design Speed :
400m/min
Description

4400mm Waste Paper Wood Pulp Kraft Paper And Testliner

Paper White Top Paper Making Machine

1

Output paper

kraft corrugated paper, testliner paper,white kraft paper

2

Raw material

waste paper, old carton box, wood pulp, straw

3

Capacity

200T/d

4

paper weight

100-300G/M2

5

Net paper width

4400mm

(adjust according to clients’ requirement)

6

Rail space

5400mm

7

Working Speed

150-350m/min

8

Design Speed

400m/min

9

Drive and control

Alternating current, frequency conversion, speed control, section drive ;

Process flow

waste paper → high consistency hydrapulper → high frequency vibrating screen

→ pulp pump → efficient double disc pulp refiner → pulp pump → chest agitator

→ pulp pump → centrifugal screen → pulp pump → impurity remover → paper

machine → calendar → winding machine → rewinding machine

Characteristic of recycling machine for paper

Headbox

• Excellent component element intefration, unique flow channel design. The special

flow channel can jet the pulp evenly, and no fiber and dust stayed.

• Adjustable slice angle designed, is can be adjusted at any time.

• Rotproof stainless steal, durable usage time.

• Multi-material adoption, high efficiency.

• Basic Weight

Suction Cylinder

• Special design for hole drilling, insure high efficient water dehydration..

• Steam and water automatic separate design, minimize ther energy consumption.

• Rotproof stainless steal, durable usage time.

Suction Touch Roll

• The roll is covered by polyurethane, and with groove on the surface

• After the suction touch roll, the water dehydraton can up to 36%

• Suction Box

High efficiency and durable.

• Vacuum Pump

Low energy consumption, low maintain cost and low noise. Double vacuum pump,

helping the operator has better control and monitoring the machine.

• Horizontal Screen

High precision, High efficiency and Muli-material adoption.

• Fan pump

Low-pulse, low energy consumption and stable flow pumping.

• Horizontal Wave Doctor Blade System

Enhance the blade duration time and reduce the paper break frequency and protect

the Yankee Cylinder.

• PEO Supply System

Mix the pulp and PEO fatly and evenly.
