24 Circuits Fluid Rotary Joint Slip Ring 3MPa Integrated With A Threaded Tube Fitting
24 Circuits Fluid Rotary Joint Slip Ring 3MPa Integrated With A Threaded Tube Fitting
24 Circuits Fluid Rotary Joint Slip Ring 3MPa Integrated With A Threaded Tube Fitting
24 Circuits Fluid Rotary Joint Slip Ring 3MPa Integrated With A Threaded Tube Fitting
Specifications
Brand Name :
Panlink
Model Number :
PSR-F15-24&RC2
Certification :
ISO 9001: 2015, CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Packaging Details :
Carton Box, EPE Foam, Wooden Box(For Large Goods)
Media Types :
Air
operating pressure range :
-100kpa to 1Mpa
proof pressure :
3MPa
Tube OD :
10mm
Circuits :
24 x Signal(2A）
Speed :
100rpm
Name :
Fluid Rotary Joint
Price :
Negotiable
Delivery Time :
4 Weeks
Supply Ability :
40 Million a Year
Description

24 Circuits Slip Ring integrated with a threaded tube fitting for Electrical Signal and Fluid Transmission

Fluid + Electrical Solutions for High-Precision Instruments

Feature Application
• Media Types: Air • Assembly Robot Wrist
• Operating Pressure Range: -100kpa to 1Mpa • Dynamic Performance Simulation Test Bench
• Proof Pressure: 3MPa • Packaging, Filling, and Medical Equipment
• Tube OD: 10mm
• Circuits: 24 x Signal(2A)

24 Circuits Fluid Rotary Joint Slip Ring 3MPa Integrated With A Threaded Tube Fitting

Specification
Model PSR-F15-24&RC2
Circuit 24 x Signal(2A)
Voltage 220vac
Insulation Resistance 500MΩ@500VDC
Electrical Noise 40mΩ max
Dielectric Strength 500VAC@50Hz
Operating Speed 100rpm
Torque ≤0.4N.m
Contact Material Precious Metal
Housing Material Aluminium Alloy
Working Temperature -20℃~+70℃
Storage Temperature -25℃~+80℃
Humidity 95±3%(30℃+5℃)
Protection Level IP54
Lifetime 50 million revolutions
Rotary Joint Specification
Channel 1
Min Port Size 7
Operating Pressure Range -100kpa to 1Mpa
Proof Pressure 3MPa
Torque 0.02N.M
Media Air
Temperature -25℃~+80℃
Body BPT
