Compact 85mm OD, Solid-Shaft Slip Ring with 2 x K-type Thermocouple Signals, Engineered for Heaters and Heating Drums
Compact 85mm OD, Solid-Shaft Slip Ring with 2 x K-type Thermocouple Signals, Engineered for Heaters and Heating Drums
Compact 85mm OD, Solid-Shaft Slip Ring with 2 x K-type Thermocouple Signals, Engineered for Heaters and Heating Drums
Compact 85mm OD, Solid-Shaft Slip Ring with 2 x K-type Thermocouple Signals, Engineered for Heaters and Heating Drums
Specifications
Brand Name :
Panlink
Model Number :
PSR-TS-2P2S
Certification :
ISO 9001: 2015, CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
40 Million a Year
Delivery Time :
4 Weeks
Packaging Details :
Carton Box, EPE Foam, Wooden Box(For Large Goods)
OD x L :
3.35″ x 2.76″/ 85mm x 70mm
Signals :
2 x Thermocouple Signals
Voltage :
220VAC
Lead Wire :
K-Type thermocouple channels
Working Temperature :
-4℉~+302°F (-20℃~+150℃)
Description

Compact 85mm OD, Solid-Shaft Slip Ring with 2 x K-type Thermocouple Signals, Engineered for Heaters and Heating Drums

85mm OD Slip Ring with Dual K-Type Thermocouple Channels

Features Applications

• OD x L: 3.35″ x 2.76″/ 85mm x 70mm

• Heating Rollers

• Signals: 2 x Thermocouple Signals

• Intelligent Electromagnetic Ovens

• Voltage: 220VAC

• Plastic Film Production Equipment

• Lead wire: K-Type thermocouple channels

• Cigarette Machine Cutting Drum

• Working temperature: -4℉~+302°F (-20℃~+150℃)

• Electromagnetic Baking Equipment Drums

Compact 85mm OD, Solid-Shaft Slip Ring with 2 x K-type Thermocouple Signals, Engineered for Heaters and Heating Drums

Model

Bore DIA

inch(mm)

Size: OD x L

inch (mm)

 Circuits Voltage

Speed

(rpm)

 Total Rings
PSR-TS-2P2S /

3.35″ x 2.76″

(85 x 70)

 2A, 10A 220VAC 300 4
Specifications
Circuits 2×power(10A); 2×signal(2A)
Insulation Resistance 100MΩ@500VDC
Electrical Noise Max. 40mΩ
Dielectric Strength 500VAC@50Hz,60s
Torque Max. 1.0 N.M
Working Temperature -4℉~+302°F (-20℃~+150℃)
Storage Temperature -35℉~+302°F (-25℃~+150℃)
Relative Humidity 95±3%(30℃+5℃)
Protection Level IP54
Contact Material Precious Metal
Housing Material Aluminum Alloy
Lead Wire K-Type thermocouple channels
