111 Circuit Hybrid Slip Ring IP54 for High Signal Density Industrial
111 Circuit Hybrid Slip Ring IP54 for High Signal Density Industrial
111 Circuit Hybrid Slip Ring IP54 for High Signal Density Industrial
111 Circuit Hybrid Slip Ring IP54 for High Signal Density Industrial
Specifications
Brand Name :
Panlink
Model Number :
LTTS105STY
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Certification :
ISO 9001: 2015, CE
Packaging Details :
Carton Box, EPE Foam, Wooden Box(For Large Goods)
Name :
Hybrid Slip Ring
Circuits :
18 × power; 93 × signal
Contact Resistance :
40mΩ
Contact Material :
Precious Metal
Housing Material :
Aluminum Alloy
Price :
Negotiable
Delivery Time :
4 Weeks
Supply Ability :
40 Million a Year
Description

111-Circuit Hybrid Slip Ring (18xPower + 93xSignal, 4 A max) Engineered for High-Signal-Density Industrial, Military and High-End Automation Applications

Features Applications

• High-Density Signaling: 93 channels for extensive data, control,

• Radar antenna pedestal
and sensor transmission.

• Turret system

• Superior Signal Integrity: low contact resistance (40mΩ).

• Port crane / marine crane
• Flexible Power Distribution: Dedicated circuits for components

• Large rotary kiln / converter

with varying power needs.

• CMM

• Rugged Design: Wide operating temperature range

and IP54 protection.

• Large-scale mine-clearance / EOD

robot

111 Circuit Hybrid Slip Ring IP54 for High Signal Density Industrial

Model

Bore DIA

inch(mm)

Size: OD x L

inch (mm)

 Circuits Voltage

Speed

(rpm)
LTTS105STY /

5.12″ x 12.8″

(130 x 325)

18×power

93×signal

 500VDC/50VDC 30
Specifications
Circuits 18×power; 93×signal
Insulation Resistance 100MΩ@500VDC
Electrical Noise Max. 40mΩ
Dielectric Strength 1000VAC@50Hz,60s
Torque Max. 2.0 N.M
Working Temperature -4℉~+131℉(-20℃~+55℃)
Storage Temperature -35℉~+167℉(-25℃~+75℃)
Relative Humidity 95±3%(30℃+5℃)
Protection Level IP54
Contact Material Precious Metal
Housing Material Aluminum Alloy
