Single Channel SM Fiber Optic Slip Ring with 72 Electrical Circuits and 50 Million Revolutions Lifetime for Signal and Power Transmission
Single Channel SM Fiber Optic Slip Ring with 72 Electrical Circuits and 50 Million Revolutions Lifetime for Signal and Power Transmission
Single Channel SM Fiber Optic Slip Ring with 72 Electrical Circuits and 50 Million Revolutions Lifetime for Signal and Power Transmission
Single Channel SM Fiber Optic Slip Ring with 72 Electrical Circuits and 50 Million Revolutions Lifetime for Signal and Power Transmission
Specifications
Brand Name :
Panlink
Model Number :
PSR-T25S-12P60S&MJX
Certification :
ISO 9001: 2015, CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Packaging Details :
Carton Box, EPE Foam, Wooden Box(For Large Goods)
Price :
Negotiable
Delivery Time :
4 Weeks
Supply Ability :
40 Million a Year
Fiber Optic :
1 x SM
Electrical :
2 x Power(20A）+ 10 x Power(8A) + 60 x Signal
Wavelength Range :
1310-1550nm
Protection Level :
IP54
Lifetime :
50 million revolutions
Name :
Fiber Optic Rotary Joint
Description

Single Channel SM Fiber Optic and Electrical Slip Ring Supporting High-Performance Power, Signal and Media Transmission

72 Electrical + 1 FORJ Integration

Features Applications
• Fiber Optic: 1 x SM • Satellite Communication Systems
• Electrical: 2 x Power(20A)+ 10 x Power(8A) + 60 x Signal • Medical Treatment Equipment
• Wavelength Range: 1310-1550nm • Radar Antennas
• Protection Level: IP54 • Military Systems
• Lifetime: 50 million revolutions • HD Network Monitoring Systems
• Connector: • Air Traffic Control
• Camera Technology

Single Channel SM Fiber Optic Slip Ring with 72 Electrical Circuits and 50 Million Revolutions Lifetime for Signal and Power Transmission

Model PSR-T25S-12P60S&MJX
Circuits 72 + 1 FORJ
Current 2 x Power(20A)+ 10 x Power(8A) + 60 x Signal
Voltage 48VDC
Insulation Resistance 200MΩ@500VDC
Dielectric Strength 500VAC@50Hz
Rotating Speed 300rpm
Torque Max 0.2N.M
Lifetime 50 million revolutions
Working Temperature -40℃~+80℃
Storage Temperature -45℃~+85℃
Humidity 95±3%
Vibration 10~30 Frequency Double Amplitude 0.8mm
30~200HZ Frequency, acceleration 2g
two circulationtotal 30 mi
Rush

40g, 11mss, half sine wave, Vertical direction 3 times,

Level 3 times
Protection Level IP54
Contact Material Precious Metal
Housing Material Aluminium Alloy
Leadwire Teflon
Fiber Optic Specification
Wavelength Range 1310-1550nm
Inserlation Loss ＜2dB(Typical: ＋/- 0.15dB
Returen Loss ＞40dB(Typical:45dB, 23℃)
Maximum Speed 2,000rpm
Pressure Compensation 10,000psi
Torque ＜0.1N.M
Pulling Strength 10N
Fiber Type Single Mode w/3 mm jacke
Weight 50g
Housing Material Stainless Steel
Working Temperature -40℃~+65℃
Lifetime 200-400 million revolutions
