4+1 Axis CNC Hydraulic Press Brake Multifunctional 90mm Worktable Width
4+1 Axis CNC Hydraulic Press Brake Multifunctional 90mm Worktable Width
4+1 Axis CNC Hydraulic Press Brake Multifunctional 90mm Worktable Width
4+1 Axis CNC Hydraulic Press Brake Multifunctional 90mm Worktable Width
4+1 Axis CNC Hydraulic Press Brake Multifunctional 90mm Worktable Width
4+1 Axis CNC Hydraulic Press Brake Multifunctional 90mm Worktable Width
Specifications
Brand Name :
D.K.Histron
Model Number :
HC-110T/3200
Certification :
ISO9001,CE
Place of Origin :
China
MOQ :
1 Set
Price :
depends on model
Payment Terms :
T/T
Supply Ability :
20sets/month
Delivery Time :
50 days
Packaging Details :
by customer's requirements
Product name :
CNC Hydraulic Bending Machine
Material / metal processed :
Stainless Steel, Carbon Steel, ALLOY, Aluminum, Brass / Copper
Automation :
Automatic, manual, Foot-operated, Semi-automatic
Extra services :
End Forming, Machining, Cut To Length, Swaging,Support customized
Warranty :
1 Year
Color :
Blue, Customized, optional, Grey, Red
Voltage :
220V/380V/415V/440V/customized, 220V/380V/400V,380V or as required,User define
Type :
Metal bending machine
Description
Hydraulic Steel Plate Bending Machine Multifunctional Sheet Metal Hydraulic Press Brake Machine
This hydraulic steel plate bending machine features a multifunctional design for sheet metal hydraulic press brake operations. Built with hard steel Q235A welding and complete structure processing, the machine undergoes VBR treatment for enhanced durability.
Key Features
  • Hard steel Q235A welding with whole structure processing and VBR treatment
  • Modern design with attractive appearance
  • High precision processing ensures accurate metal bending
  • Utilizes famous brand components for reliability
  • Customizable painting color to meet your requirements
Product Description
The machine features an overall welded and processed structure, with main components analyzed using ANSYS finite element analysis software to ensure reliability and precision. The CNC control system utilizes renowned brand products capable of graphic programming for bending angles, angle amendment compensation, automatic calculation and adjustment of bending pressure, automatic calculation of workbench distortion compensation, workpiece length extension, bottom bending open distance pressure, and automatic rear stopper withdrawal.
Technical Parameters
Parameter Specification
Model HC-110T/3200
Normal force 1100KN
Worktable length 3200mm
Worktable width 90mm
Distance between columns 2700mm
Hose depth 350mm
Slider stroke 200mm
Maximum opening height 450mm
Wall panel column thickness 50mm
Slider thickness 60mm
Worktable upright plate thickness 80mm
Main motor power - oil pump Motor 11KW-Oil pump 25ml/r
Slider rapid descent speed 180mm/s
Slider return speed 150mm/s
Slider working speed 10mm/s
CNC system DA53T
Number of controlled axes 4 +1 axes
Back gauge X-axis stroke 600mm
Back gauge X-axis speed 200mm/s
External dimensions 3600*1700*2800mm
Product Images
4+1 Axis CNC Hydraulic Press Brake Multifunctional 90mm Worktable Width 4+1 Axis CNC Hydraulic Press Brake Multifunctional 90mm Worktable Width 4+1 Axis CNC Hydraulic Press Brake Multifunctional 90mm Worktable Width

4+1 Axis CNC Hydraulic Press Brake Multifunctional 90mm Worktable Width

4+1 Axis CNC Hydraulic Press Brake Multifunctional 90mm Worktable Width

Frequently Asked Questions
What kind of documents can you supply?
We provide documents according to customer requests, including Certificate of Origin, Insurance, and other export documentation.
What is the average lead time?
Lead time is approximately 50 days after receiving deposit payment.
What is the guarantee period?
Our product quality guarantee period is 12 months from B/L date. During this period, we provide spare parts free of charge for quality discrepancies caused by us. For malfunctions due to incorrect customer operations, we offer spare parts at cost price. Flexible extended warranties are available based on actual requirements.
Why Choose Us?
Our teams provide professional, customized, and comprehensive services around the clock.
Contact us via WhatsApp, Skype, Email, or Telephone for assistance.
