Custom Color Optical Fiber Patch Cord SM MM LC UPC Fiber Optic Pigtail Low Insertion Loss
Custom Color Optical Fiber Patch Cord SM MM LC UPC Fiber Optic Pigtail Low Insertion Loss
Specifications
Brand Name :
MingTong
Certification :
ISO
Place of Origin :
Dongguan CHINA
Price :
5-200RNB/P
Payment Terms :
L/C,T/T
Delivery Time :
It depends on the actual situation
MOQ :
200
Packaging Details :
cardboard box
Supply Ability :
2000 copies/Day
Name :
Fiber Optic Patch Cord
Polish :
UPC,APC
Fiber Type :
SM/MM
Connector :
SC,FC,LC,ST,MU,DIN,MTRJ,E2000,MPO
Cord Type :
Simplex ,Duplex
Cable Jacket :
PVC,LSZH,OFNR,OFNP
Highlight :
pigtail fiber optic cable, ofc pigtail
Description
Good In Exchange Fiber Optic Patch Cord SM MM Fiber Pigtail Connector LC / UPC
LC/UPC Fiber Optic Pigtail
Custom Color Optical Fiber Patch Cord SM MM LC UPC Fiber Optic Pigtail Low Insertion Loss

The LC pigtail fiber optic cable has connectors on one end for fast and easy connection to CATV, optical switches, or other telecom equipment. It's available in single mode and multimode versions, and features an LC connector with a zirconia ceramic ferrule, pre-polished PC profile, and convex spherical end.

Custom Color Optical Fiber Patch Cord SM MM LC UPC Fiber Optic Pigtail Low Insertion Loss Custom Color Optical Fiber Patch Cord SM MM LC UPC Fiber Optic Pigtail Low Insertion Loss

By allowing for faster polishing, low back reflection, and optical loss, these end-face types ensure maximum repeatability.

Features
  • Low insertion loss and back reflection loss
  • Ferrule end surface is pre-domed
  • Excellent mechanical endurance
  • Good in repeatability
  • Good in exchange
Applications
  • Telecommunications
  • CATV, LAN, MAN, WAN, Test & Measurement
  • Military industry
  • Medical
Technical Parameters
Parameter Unit PC(SM) UPC(SM) APC(SM) PC(MM)
Insertion Loss (Typical) dB ≤0.3 ≤0.3 ≤0.2 ≤0.2
Return Loss dB ≥45 ≥50 ≥60 ≥35
Mechanical Endurance (500T) dB ≤0.2
Exchangeability dB ≤0.2
Durability Time ＞500
Vibration dB ≤0.2
Operating Temperature ℃ ﹣40 ～﹢75
Storage Temperature ℃ ﹣45 ～﹢85
Cable Diameter mm Ф2.0mm± 2%
Fiber Characteristics
Item Specification Construction
Fiber Type Single mode: G652, Multimode: G651
Mode Field Diameter @1310nm 9.0±0.5μm
Cladding Diameter 125±1μm
Core Concentricity Error ≤ 0.6μm
Cladding Non-Circularity ≤ 1.0%
Primary Coating Diameter 250±15μm
Coating-Cladding Concentricity Error ≤ 12.5μm
Fiber Curl Radius ≥ 4m
Casing LSZH or better (OFNR-rated). The non-circular < 2%. Yellow color printed cables information, type, length
The Bend Radius 3 cm
Greatest Tension Installation: ≥ 200 N
Operating: ≥ 200 N
The Force Mashed 550 N/cm
