Low Profile 250A-630A Auxiliary Power Busway System for AI Data Center Ancillary Loads
Low Profile 250A-630A Auxiliary Power Busway System for AI Data Center Ancillary Loads
Specifications
Rated Voltage :
AC 690V
Insulation Class :
Class B (130°C)
Temperature Rise :
≤ 70K at rated current
Brand Name :
ohory
Conductor Material :
High-conductivity copper conductors
Delivery Time :
Depends On Total Quantity
Protection Grade :
IP44
Packaging Details :
Wooden Box
Profile Height :
Ultra low profile for ceiling void installation
Place of Origin :
Guangdong, China
Dielectric Withstand :
3,750V AC / 1 min
Payment Terms :
T/T
Price :
Negotiable
Certification :
ISO 9001/UL/IEC/CNAS/CMA
MOQ :
188 Meters
Supply Ability :
1500 Meters Per Day
Model Number :
OH-APB-630A
Application :
AI computing power centers, AI data centers, GPU clusters, high-density AI racks
Rated Current :
250A - 630A
Short-Circuit Withstand :
35kA / 1s
Description
Auxiliary Power Busway System 250A-630A Low Profile For AI Data Center Ancillary Loads
This low profile auxiliary busway system powers the supporting loads of AI data centers, including cooling equipment, lighting and general services. Rated 250A to 630A, its slim profile installs easily above ceiling voids and along service corridors, keeping main power capacity for IT loads.
Core Advantages
  • Dedicated Ancillary Power: Separates cooling, lighting and building service loads from critical IT power paths.
  • Low Profile Enclosure: Ultra slim cross-section fits tight ceiling voids and congested service routes.
  • Simple Overhead Mounting: Lightweight sections install quickly with minimal support steel.
  • Cost Effective Distribution: Right-sized rating avoids overspending on ancillary power infrastructure.
Technical Specifications
Parameter Value
Rated Current 250A - 630A
Rated Voltage AC 690V
Dielectric Withstand 3,750V AC / 1 min
Short-Circuit Withstand 35kA / 1s
Insulation Class Class B (130°C)
Protection Grade IP44
Conductor Material High-conductivity copper conductors
Profile Height Ultra low profile for ceiling void installation
Temperature Rise ≤ 70K at rated current
Applications
  • Cooling equipment and HVAC power in AI data centers
  • Lighting and general service distribution
  • Ancillary loads in AI computing power centers
  • Service corridors and support zones of AI data halls
Quality & Service
Manufactured under ISO 9001 quality management with UL/IEC/CNAS/CMA certified testing. OEM and ODM support available, with complete drawings and technical documentation provided upon request.
