AI+ Intelligent Busway System with Rapid Tap-Off Configuration and Online Installation for Scalable Rack Deployment
AI+ Intelligent Busway System with Rapid Tap-Off Configuration and Online Installation for Scalable Rack Deployment
AI+ Intelligent Busway System with Rapid Tap-Off Configuration and Online Installation for Scalable Rack Deployment
AI+ Intelligent Busway System with Rapid Tap-Off Configuration and Online Installation for Scalable Rack Deployment
Specifications
Rated Current :
1,250A - 6,300A
Certification :
ISO 9001/UL/IEC/CNAS/CMA
Packaging Details :
Wooden Box
Place of Origin :
Guangdong, China
Payment Terms :
T/T
Operating Temperature :
-20°C to +60°C
MOQ :
188 Meters
Delivery Time :
Depends On Total Quantity
Temperature Rise :
≤ 30 K at full load
Partial Discharge :
≤ 5 pC
Insulation Technology :
Molecular-Shield solid insulation
Supply Ability :
1500 Meters Per Day
Protection Grade :
IP68
Brand Name :
ohory
Model Number :
AI+IB-TAP
Rated Voltage :
AC 690V
Price :
Negotiable
Tap-Off Mode :
Rapid configuration, online installation
Application :
AI data centers, GPU clusters, HPC, 100kW-class high-density racks, UPS output to rack rows
Power-Frequency Withstand :
8 kV
Description
AI+ Intelligent Busway System Rapid Tap Off Configuration Power Points Follow Demand For AI Data Centers
Product Overview

AI+ Intelligent Busway System with Rapid Flexible Tap-Off Configuration. In AI data centers, rack power, location and deployment pace change constantly. This AI+ intelligent busway allows tap-off points to be rapidly configured along rack rows, so power points follow the business: add, move or upgrade rack power quickly and support future expansion without re-engineering the backbone.

Core Advantages
  • Rapid Tap-Off Configuration: Power points can be configured around rack location, load and deployment schedule
  • Power Points Follow Business: Tap-off layout adapts as AI workloads, rack rows and construction phases change
  • Online Tap-Off Installation: New tap-off boxes install while energized, supporting zero-interruption modification
  • Scalable Rack Deployment: From a few racks to full GPU cluster halls, the same backbone grows with demand
Technical Specifications
Parameter Value
Tap-Off Mode Rapid configuration, online installation
Rated Current 1,250A - 6,300A
Rated Voltage AC 690V
Power-Frequency Withstand 8 kV
Partial Discharge ≤ 5 pC
Temperature Rise ≤ 30 K at full load
Protection Grade IP68
Operating Temperature -20°C to +60°C
Insulation Technology Molecular-Shield solid insulation
Applications
  • AI data centers and AI computing power centers
  • GPU clusters and HPC computing halls
  • 100kW-class high-density server racks
  • UPS output to high-density rack row power distribution
Quality & Service
Manufactured under ISO 9001 quality management with UL/IEC/CNAS/CMA certified testing. Intelligent busway system delivered with monitoring platform access, installation guidance and technical documentation. OEM and ODM support available.
