AI+ Intelligent Busway System with Low Temperature Rise ≤ 30K and Molecular-Shield Solid Insulation for AI Data Centers
AI+ Intelligent Busway System with Low Temperature Rise ≤ 30K and Molecular-Shield Solid Insulation for AI Data Centers
Specifications
Rated Current :
1,250A - 6,300A
Place of Origin :
Guangdong, China
Supply Ability :
1500 Meters Per Day
Delivery Time :
Depends On Total Quantity
Protection Grade :
IP68
Packaging Details :
Wooden Box
Partial Discharge :
≤ 5 pC
Monitoring :
Joint temperature and temperature-rise-rate sensing
Operating Temperature :
-20°C to +60°C
Brand Name :
ohory
Model Number :
AI+IB-30K
Insulation Technology :
Molecular-Shield solid insulation
Rated Voltage :
AC 690V
Certification :
ISO 9001/UL/IEC/CNAS/CMA
Power-Frequency Withstand :
8 kV
Price :
Negotiable
Payment Terms :
T/T
Temperature Rise :
≤ 30 K at full load
MOQ :
188 Meters
Application :
AI data centers, GPU clusters, HPC, 100kW-class high-density racks, UPS output to rack rows
Description
AI+ Intelligent Busway System Low Temperature Rise 30K Full Load Operation For AI Data Center Thermal Stability
Product Overview

AI+ Intelligent Busway System with Low Temperature Rise for Long-Duration Full-Load Operation. Heat is the hidden enemy of high-density AI power distribution. This AI+ intelligent busway achieves a temperature rise of no more than 30K at full load thanks to Molecular-Shield insulation with a continuous heat-dissipation path, supporting sustained 100kW-class rack operation without connection overheating.

Core Advantages
  • 30K Full-Load Temperature Rise: Verified low temperature rise protects joints and connections during continuous high-current AI operation.
  • Continuous Heat Path: Integral molded insulation improves heat dissipation compared with wrapped film designs.
  • Connection Risk Reduction: Lower thermal stress slows oxidation and loosening at tap-off and joint points.
  • Long-Term Reliability: Stable thermal performance extends service life and reduces unplanned maintenance.
Technical Specifications
Parameter Value
Temperature Rise ≤ 30 K at full load
Rated Current 1,250A - 6,300A
Rated Voltage AC 690V
Power-Frequency Withstand 8 kV
Partial Discharge ≤ 5 pC
Protection Grade IP68
Operating Temperature -20°C to +60°C
Insulation Technology Molecular-Shield solid insulation
Monitoring Joint temperature and temperature-rise-rate sensing
Applications
  • AI data centers and AI computing power centers
  • GPU clusters and HPC computing halls
  • 100kW-class high-density server racks
  • UPS output to high-density rack row power distribution
Quality & Service

Manufactured under ISO 9001 quality management with UL/IEC/CNAS/CMA certified testing. Intelligent busway system delivered with monitoring platform access, installation guidance and technical documentation. OEM and ODM support available.
