Vertical Riser Busway System 800A-3200A Main Feeder with High-Conductivity Copper Conductors and Single Bolt Torque Controlled Joint for AI Data Centers
Vertical Riser Busway System 800A-3200A Main Feeder with High-Conductivity Copper Conductors and Single Bolt Torque Controlled Joint for AI Data Centers
Specifications
Place of Origin :
Guangdong, China
Rated Voltage :
AC 690V
Insulation Class :
Class B (130°C)
Temperature Rise :
≤ 70K at rated current
Conductor Material :
High-conductivity copper conductors
Certification :
ISO 9001/UL/IEC/CNAS/CMA
Packaging Details :
Wooden Box
MOQ :
188 Meters
Protection Grade :
IP54
Joint Type :
Single bolt torque controlled joint for rapid erection
Model Number :
OH-VRB-3200A
Supply Ability :
1500 Meters Per Day
Delivery Time :
Depends On Total Quantity
Brand Name :
ohory
Dielectric Withstand :
3,750V AC / 1 min
Payment Terms :
T/T
Short-Circuit Withstand :
80kA / 1s
Price :
Negotiable
Rated Current :
800A - 3,200A
Application :
AI computing power centers, AI data centers, GPU clusters, high-density AI racks
Description
Vertical Riser Busway System 800A-3200A Main Feeder For AI Data Center UPS Output

This vertical riser busway system carries power from UPS output rooms to every floor of multi-story AI data centers. Rated 800A to 3,200A, it replaces bulky cable bundles with a compact riser, reducing installation cost and freeing shaft space for cooling and networking infrastructure.

Core Advantages
  • High Rise Main Feeder: Reliable vertical power riser connecting UPS output to floor distribution busways
  • Space Saving Riser: Compact footprint in electrical shafts leaves more room for AI facility services
  • Lower Installation Cost: Faster erection than parallel cable trays, reducing labor and material expense
  • Floor Tap-Off Ready: Take-off points at each floor feed AI rack rows and cooling infrastructure directly
Technical Specifications
Parameter Value
Rated Current 800A - 3,200A
Rated Voltage AC 690V
Dielectric Withstand 3,750V AC / 1 min
Short-Circuit Withstand 80kA / 1s
Insulation Class Class B (130°C)
Protection Grade IP54
Conductor Material High-conductivity copper conductors
Joint Type Single bolt torque controlled joint for rapid erection
Temperature Rise ≤ 70K at rated current
Applications
  • AI computing power centers and AI data centers
  • GPU cluster rooms and high-density AI server racks
  • UPS output to AI rack power distribution units (PDU)
  • Colocation and enterprise data halls with high-density AI workloads
Quality & Service

Manufactured under ISO 9001 quality management with UL/IEC/CNAS/CMA certified testing. OEM and ODM support available, with complete drawings and technical documentation provided upon request.
