Lightweight Aluminum Conductor Busway 400A-4000A for AI Colocation Data Centers
Lightweight Aluminum Conductor Busway 400A-4000A for AI Colocation Data Centers
Specifications
MOQ :
188 Meters
Delivery Time :
Depends On Total Quantity
Temperature Rise :
≤ 70K at rated current
Dielectric Withstand :
3,750V AC / 1 min
Payment Terms :
T/T
Model Number :
OH-ACB-4000A
Place of Origin :
Guangdong, China
Supply Ability :
1500 Meters Per Day
Rated Voltage :
AC 690V
Conductor Material :
High-grade aluminum alloy, tin plated joints
Price :
Negotiable
Packaging Details :
Wooden Box
Protection Grade :
IP54
Certification :
ISO 9001/UL/IEC/CNAS/CMA
Insulation Class :
Class B (130°C)
Weight Advantage :
Approx. 40% lighter than equivalent copper busway
Rated Current :
400A - 4,000A
Application :
AI computing power centers, AI data centers, GPU clusters, high-density AI racks
Brand Name :
ohory
Short-Circuit Withstand :
65kA / 1s
Description
Aluminum Conductor Busway 400A-4000A Lightweight Design For AI Colocation Data Centers
This aluminum conductor busway system is the cost-efficient choice for AI colocation data centers. Rated 400A to 4,000A, its lightweight aluminum conductors reduce structural loading and simplify installation, while precision alloy processing keeps joints stable and power delivery reliable.
Core Advantages
  • Lightweight Structure: Aluminum conductors cut total busway weight, reducing ceiling and support structure requirements
  • Economical Solution: Lower material cost makes large-scale AI colocation rollouts more budget efficient
  • Easy Installation: Lighter sections enable faster rigging and shorter commissioning time on site
  • Reliable Joint Design: Tin plated and torque controlled connections maintain low resistance over the long term
Technical Specifications
Parameter Value
Rated Current 400A - 4,000A
Rated Voltage AC 690V
Dielectric Withstand 3,750V AC / 1 min
Short-Circuit Withstand 65kA / 1s
Insulation Class Class B (130°C)
Protection Grade IP54
Conductor Material High-grade aluminum alloy, tin plated joints
Temperature Rise ≤ 70K at rated current
Weight Advantage Approx. 40% lighter than equivalent copper busway
Applications
  • AI computing power centers and AI data centers
  • GPU cluster rooms and high-density AI server racks
  • UPS output to AI rack power distribution units (PDU)
  • Colocation and enterprise data halls with high-density AI workloads
Quality & Service: Manufactured under ISO 9001 quality management with UL/IEC/CNAS/CMA certified testing. OEM and ODM support available, with complete drawings and technical documentation provided upon request.
