2000A-6300A Low Temperature Rise Busway System with High-Conductivity Copper for AI Data Center Power Backbone
2000A-6300A Low Temperature Rise Busway System with High-Conductivity Copper for AI Data Center Power Backbone
Specifications
Rated Voltage :
AC 690V
Payment Terms :
T/T
Protection Grade :
IP54
Certification :
ISO 9001/UL/IEC/CNAS/CMA
Temperature Rise :
≤ 65K at rated current
Model Number :
OH-HCB-6300A
Packaging Details :
Wooden Box
Dielectric Withstand :
3,750V AC / 1 min
Delivery Time :
Depends On Total Quantity
Price :
Negotiable
Supply Ability :
1500 Meters Per Day
Insulation Class :
Class C (150°C optional)
Application Position :
Main power backbone for AI training clusters
Conductor Material :
High-conductivity copper with silver plated joints
MOQ :
188 Meters
Brand Name :
ohory
Short-Circuit Withstand :
100kA / 1s
Place of Origin :
Guangdong, China
Rated Current :
2,000A - 6,300A
Application :
AI computing power centers, AI data centers, GPU clusters, high-density AI racks
Description
High Current Busway System 2000A-6300A Low Temperature Rise For AI Training Cluster Backbone
Product Overview

This high current busway system serves as the main power backbone for AI training clusters and supercomputing halls. Rated 2,000A to 6,300A, its oversized conductors and optimized ventilation keep temperature rise low even under sustained peak GPU training loads, maximizing power delivery stability.

Core Advantages
  • Ultra High Current Capacity: Up to 6,300A continuous rating supports entire AI training cluster rows from a single backbone
  • Low Temperature Rise: Generous conductor cross-section and heat dissipation design keep operating temperatures stable at full load
  • Heavy Duty Construction: Reinforced enclosure and high strength insulation withstand vibration and mechanical stress in large data halls
  • Low Energy Loss: Reduced impedance lowers joule losses across long feeder runs, cutting AI facility operating cost
Technical Specifications
Rated Current 2,000A - 6,300A
Rated Voltage AC 690V
Dielectric Withstand 3,750V AC / 1 min
Short-Circuit Withstand 100kA / 1s
Insulation Class Class C (150°C optional)
Protection Grade IP54
Conductor Material High-conductivity copper with silver plated joints
Temperature Rise ≤ 65K at rated current
Application Position Main power backbone for AI training clusters
Applications
  • AI computing power centers and AI data centers
  • GPU cluster rooms and high-density AI server racks
  • UPS output to AI rack power distribution units (PDU)
  • Colocation and enterprise data halls with high-density AI workloads
Quality & Service

Manufactured under ISO 9001 quality management with UL/IEC/CNAS/CMA certified testing. OEM and ODM support available, with complete drawings and technical documentation provided upon request.
