LR60F-1Z 100A High Power Relay SPDT 1 Changeover Contact Bolt Mounting 60.2x46x40mm
LR60F-1Z 100A High Power Relay SPDT 1 Changeover Contact Bolt Mounting 60.2x46x40mm
Specifications
Dimensions (W x H x D) :
60.2 x 46 x 40 mm
Dielectric Strength :
2500 VAC
Rated Switching Voltage :
250VAC / 30VDC
Payment Terms :
T/T,L/C,PayPal
Place of Origin :
Guangdong, China
Load Switching Capability :
100A
Contact Material :
Silver Alloy
Supply Ability :
50000 Pieces per Month
Packaging Details :
Export-grade corrugated carton with anti-static foam insert, 100 pcs per carton
Insulation Resistance :
1000 MOhm Min
Brand Name :
Rocfly
Model :
LR60F-1Z
Contact Forms :
1Z (SPDT, one changeover contact)
Mounting Type :
Bolt Mounting
Delivery Time :
3 working days for stock, 15-25 days for production
Operating Temperature :
-40 C to +70 C
Model Number :
LR60F-1Z
Certification :
ISO 9001:2015
Description

LR60F-1Z 100A High Power Relay with SPDT Changeover Contact

The LR60F-1Z is a rugged high power relay designed for heavy-duty switching in industrial machines and equipment. Offering 100A load switching capability, a single changeover (SPDT) contact form, and secure bolt mounting, this relay delivers reliable performance with a compact footprint of 60.2 x 46 x 40 mm.

Key Features

  • 60A high load and switching power - handles demanding industrial current loads with ease
  • SPDT contact form (1Z) - one changeover contact for flexible circuit control
  • Bolt mounting design - sturdy installation that withstands vibration and shock
  • Rugged, impact-resistant structure - built for long service life in tough environments
  • Compact dimensions: 60.2 x 46 x 40 mm, saving panel space
  • Silver alloy contacts for stable conductivity and reliable switching

Technical Specifications

Parameter Specification
Model LR60F-1Z
Load Switching Capability 100A
Contact Forms 1Z (SPDT, one changeover contact)
Mounting Type Bolt Mounting
Dimensions (W x H x D) 60.2 x 46 x 40 mm
Rated Switching Voltage 250VAC / 30VDC
Contact Material Silver Alloy
Insulation Resistance 1000 MΩ Min
Dielectric Strength 2500 VAC
Operating Temperature -40℃ to +70℃

Applications

The LR60F-1Z high power relay is widely used in:

  • Industrial control panels and machine tools
  • Power distribution and switching equipment
  • Motor control and automation systems
  • HVAC and elevator control circuits
  • Energy storage and charging systems

Quality Assurance

Manufactured under strict quality control with 100% functional testing, the LR60F-1Z ensures stable switching performance, strong shock and vibration resistance, and long-term reliability in your equipment.

Contact us today for LR60F-1Z pricing, datasheets, or custom relay solutions for your project.
