CNC Machined Mold Insert H13 Tool Steel with HRC 48-52 Hardness and +/-0.005mm Tolerance
CNC Machined Mold Insert H13 Tool Steel with HRC 48-52 Hardness and +/-0.005mm Tolerance
CNC Machined Mold Insert H13 Tool Steel with HRC 48-52 Hardness and +/-0.005mm Tolerance
CNC Machined Mold Insert H13 Tool Steel with HRC 48-52 Hardness and +/-0.005mm Tolerance
CNC Machined Mold Insert H13 Tool Steel with HRC 48-52 Hardness and +/-0.005mm Tolerance
CNC Machined Mold Insert H13 Tool Steel with HRC 48-52 Hardness and +/-0.005mm Tolerance
CNC Machined Mold Insert H13 Tool Steel with HRC 48-52 Hardness and +/-0.005mm Tolerance
CNC Machined Mold Insert H13 Tool Steel with HRC 48-52 Hardness and +/-0.005mm Tolerance
CNC Machined Mold Insert H13 Tool Steel with HRC 48-52 Hardness and +/-0.005mm Tolerance
CNC Machined Mold Insert H13 Tool Steel with HRC 48-52 Hardness and +/-0.005mm Tolerance
CNC Machined Mold Insert H13 Tool Steel with HRC 48-52 Hardness and +/-0.005mm Tolerance
CNC Machined Mold Insert H13 Tool Steel with HRC 48-52 Hardness and +/-0.005mm Tolerance
Specifications
Mirror Polished :
Yes
Machining Process :
CNC + EDM + Grinding
Material :
H13 Tool Steel
Model Number :
MI-H13-04
Certification :
ISO 9001:2015
Hardness :
HRC 48-52
Price :
USD 8-50 / Piece
Payment Terms :
T/T,L/C,PayPal,Western Union
Delivery Time :
7 working days for samples, 15-25 days for production
Service :
Mold Design + DFM + Mold Flow Analysis
MOQ :
10 Pieces
Tolerance :
+/-0.005mm
Brand Name :
WNRLN
Surface Finish :
Ra 0.2um
Supply Ability :
50000 Pieces per Month
Packaging Details :
WNRLN branded carton with shock-proof foam insert, export-grade corrugated carton
Place of Origin :
Guangdong, China
Description
CNC Machined Mold Insert H13 Steel Precision Mold Design Automotive Injection Tooling
CNC Machined Mold Insert H13 Steel

This CNC machined mold insert is manufactured from H13 tool steel with CNC milling, EDM and precision grinding, backed by professional mold design services for automotive plastic injection tooling.

Key Features
  • H13 tool steel hardened to HRC 48-52
  • CNC milling and EDM with +/-0.005mm tolerance
  • Mirror polished cavity surface Ra 0.2um
  • Full mold design service with DFM analysis
  • Interchangeable inserts for multi-cavity mold systems
CNC Machining Capability

High-speed CNC machining combined with wire-cut EDM and jig grinding delivers precise mold inserts with excellent surface finish and long tool life.

Mold Design & Tooling Support

Our mold design team provides complete injection mold design, DFM reports, mold flow analysis and trial-shot support for automotive parts including bumpers, dashboards and connectors.

Applications

Automotive injection molds, medical device molds, consumer electronics housings and industrial part tooling.

Technical Specifications
Material H13 Tool Steel
Hardness HRC 48-52
Machining Process CNC + EDM + Grinding
Tolerance +/-0.005mm
Surface Finish Ra 0.2um (Mirror Polished)
Service Mold Design + DFM + Mold Flow
Contact our engineering team for custom CNC machined parts, prototype tooling and mold design support. OEM and ODM orders are welcome.
