OSX010000 10G SFP Plus SR Transceiver 850nm For MMF Up To 300m Original New
OSX010000 10G SFP Plus SR Transceiver 850nm For MMF Up To 300m Original New
OSX010000 10G SFP Plus SR Transceiver 850nm For MMF Up To 300m Original New
OSX010000 10G SFP Plus SR Transceiver 850nm For MMF Up To 300m Original New
OSX010000 10G SFP Plus SR Transceiver 850nm For MMF Up To 300m Original New
OSX010000 10G SFP Plus SR Transceiver 850nm For MMF Up To 300m Original New
OSX010000 10G SFP Plus SR Transceiver 850nm For MMF Up To 300m Original New
OSX010000 10G SFP Plus SR Transceiver 850nm For MMF Up To 300m Original New
Specifications
Brand Name :
Hua wei
Model Number :
OSX010000
Certification :
CE
Place of Origin :
USA
MOQ :
1pc
Payment Terms :
T/T
Delivery Time :
1-3 working day
Price :
$35/piece
Part number :
OSX010000
Brief Description :
10G SFP Plus transceiver
Details :
850nm multimode fiber module
Key Features :
10km 10G fiber module
Condition :
Original new
Warranty :
1 year
Packing :
original new
Lead time :
1-3 working day
Ship :
DHL FEDEX UPS
Payment term :
TT in advance
original :
USA
Description

OSX010000 10G SFP Plus SR Transceiver 850nm for MMF up to 300m

Product Overview

The OSX010000 is a high performance 10G SFP Plus optical transceiver designed for short reach 10 Gigabit Ethernet applications over multimode fiber It operates at an 850 nm wavelength and delivers a data rate of 10 Gbps with transmission distances up to 300 meters on OM3 multimode fiber This hot pluggable module is ideal for high speed links within data centers enterprise core networks and top of rack switch connections

Product Details

Attribute Description
Product Name OSX010000
Form Factor SFP Plus
Data Rate 10 Gbps
Wavelength 850 nm
Interface Type LC duplex connector
Fiber Type Multimode Fiber MMF
Max Distance Up to 300 meters (OM3), 400 meters (OM4)
Operating Temperature 0C to 70C
Digital Diagnostics Yes
Compatibility IEEE 8023ae 10GBASE SR compliant
Application Data center interconnects and high density links

Key Features

Supports 10 Gbps 10 Gigabit Ethernet over multimode fiber

Operates at 850 nm wavelength for short reach connections

Transmission distance up to 300 m over OM3 and 400 m over OM4

LC duplex optical interface

Hot pluggable design for flexible deployment

Low power consumption and high reliability

Ideal for intra rack and inter rack switch links in data centers

Technical Specifications

Specification Value
Form Factor SFP Plus
Data Rate 10 Gbps
Transmission Distance 300 m OM3, 400 m OM4
Wavelength 850 nm
Connector Type LC duplex
Fiber Type Multimode MMF
Transmit Power Range minus 7 dBm to minus 1 dBm
Receive Sensitivity minus 11 dBm
Operating Temperature 0C to 70C
Voltage Supply 33V

Similar Models Comparison

Model Name Data Rate Wavelength Fiber Type Max Distance Interface
OSX010000 10 Gbps 850 nm MMF 300 m LC
SFP 10G SR 10 Gbps 850 nm MMF 300 m LC
SFP 10G LR 10 Gbps 1310 nm SMF 10 km LC
SFP 10G USR 10 Gbps 850 nm MMF 100 m LC
SFP 10G LRM 10 Gbps 1310 nm MMF 220 m LC
