Specifications
Brand Name :
Hua wei
Model Number :
QSFP28 100G 1310nm
Certification :
CE
Place of Origin :
USA
MOQ :
1pc
Payment Terms :
T/T
Delivery Time :
1-3 working day
Part number :
QSFP28 100G 1310nm
Brief Description :
single mode fiber 100G
Details :
metro 100G Ethernet
Key Features :
telecom backbone 100G
Condition :
Original new
Warranty :
1 year
Packing :
original new
Lead time :
1-3 working day
Ship :
DHL FEDEX UPS
Payment term :
TT in advance
original :
USA
Price :
$35/piece
Description

QSFP28 100G 1310nm 40km LC Optical Transceiver for Long-Distance SMF

Product Overview

The QSFP28 100G 1310 40km SM is a high-speed long-reach optical transceiver designed for 100 Gigabit Ethernet applications over single mode fiber. Operating at a 1310 nm wavelength with CWDM multiplexing, it delivers 100 Gbps through four parallel 25 Gbps channels. This module supports transmission distances of up to 40 kilometers and is ideal for telecom backbone, metro access, and long-distance data center interconnect applications. It features an LC duplex connector and complies with IEEE 802.3ba and 100GBASE-ER4 Lite standards.

Product Details

Attribute Description
Product Name QSFP28 100G 1310 40km SM
Form Factor QSFP28
Data Rate 100 Gbps (4 x 25 Gbps)
Wavelength CWDM 1270–1330 nm
Interface Type LC duplex connector
Fiber Type Single Mode Fiber (SMF)
Max Distance Up to 40 kilometers
Operating Temperature 0C to 70C
Digital Diagnostics Yes
Compatibility IEEE 802.3ba, 100GBASE-ER4 Lite
Application Long-distance Ethernet, metro network, telecom links

Key Features

Supports 100 Gbps over single mode fiber

CWDM technology over 1310 nm wavelength band

Transmission reach up to 40 km without amplification

LC duplex interface for single mode fiber

Hot pluggable QSFP28 form factor

Digital diagnostics monitoring (DDM)

Low power consumption and high reliability

Ideal for long-haul, metro, and enterprise networking

Technical Specifications

Specification Value
Form Factor QSFP28
Data Rate 100 Gbps
Transmission Distance 40 km
Wavelength 1270–1330 nm (CWDM)
Connector Type LC duplex
Fiber Type Single Mode Fiber (SMF)
Transmit Power Range –2.7 dBm to +4.5 dBm
Receive Sensitivity –15 dBm
Operating Temperature 0C to 70C
Voltage Supply 3.3V

Similar Models Comparison

Model Name Data Rate Wavelength Fiber Type Max Distance Interface
QSFP28 100G 1310 40km SM 100 Gbps 1270–1330 nm SMF 40 km LC
QSFP28 100G LR4 100 Gbps 1270–1330 nm SMF 10 km LC
QSFP28 100G ER4 100 Gbps 1310 nm SMF 40 km LC
QSFP28 100G CWDM4 100 Gbps 1271–1331 nm SMF 2 km LC
QSFP28 100G SR4 100 Gbps 850 nm MMF 100 m MPO
