QSFP28 100G LR4 1310nm 10km Optical Transceiver for Long Reach Ethernet original new in stock
QSFP28 100G LR4 1310nm 10km Optical Transceiver for Long Reach Ethernet original new in stock
QSFP28 100G LR4 1310nm 10km Optical Transceiver for Long Reach Ethernet original new in stock
QSFP28 100G LR4 1310nm 10km Optical Transceiver for Long Reach Ethernet original new in stock
QSFP28 100G LR4 1310nm 10km Optical Transceiver for Long Reach Ethernet original new in stock
QSFP28 100G LR4 1310nm 10km Optical Transceiver for Long Reach Ethernet original new in stock
QSFP28 100G LR4 1310nm 10km Optical Transceiver for Long Reach Ethernet original new in stock
QSFP28 100G LR4 1310nm 10km Optical Transceiver for Long Reach Ethernet original new in stock
Specifications
Brand Name :
Hua wei
Model Number :
QSFP28 100G LR4
Certification :
CE
Place of Origin :
USA
MOQ :
1pc
Payment Terms :
T/T
Delivery Time :
1-3 working day
Part number :
QSFP28 100G LR4
Brief Description :
100G LR4 transceiver
Details :
100GBASE LR4 module
Key Features :
LC duplex 100G optical transceiver
Condition :
Original new
Warranty :
1 year
Packing :
original new
Lead time :
1-3 working day
Ship :
DHL FEDEX UPS
Payment term :
TT in advance
original :
USA
Price :
$35/piece
Description
QSFP28 100G LR4 1310nm 10km Optical Transceiver for Long Reach Ethernet

Product Overview

The QSFP28 100G LR4 is a high-performance optical transceiver module designed for long-reach 100 Gigabit Ethernet applications over single mode fiber. It utilizes four independent 25 Gbps channels multiplexed using coarse wavelength division multiplexing (CWDM) in the 1310 nm wavelength range. Supporting transmission distances up to 10 kilometers, this module features an LC duplex connector and is compliant with IEEE 802.3ba 100GBASE-LR4 standards. It is widely used in enterprise networks, data center interconnects, and telecom backbone applications requiring reliable high-speed connectivity over long distances.

Product Details

Attribute Description
Product Name QSFP28 100G LR4
Form Factor QSFP28
Data Rate 100 Gbps (4 x 25 Gbps)
Wavelength CWDM 1270–1330 nm
Interface Type LC duplex connector
Fiber Type Single Mode Fiber (SMF)
Max Distance Up to 10 kilometers
Operating Temperature 0C to 70C
Digital Diagnostics Yes
Compatibility IEEE 802.3ba 100GBASE-LR4
Application Long-reach 100G Ethernet, data center interconnects, telecom backbone

Key Features

Supports 100 Gbps data transmission over single mode fiber

Utilizes 4-channel CWDM multiplexing for high-speed communication

Transmission distance up to 10 km

LC duplex optical interface for single mode fiber

Hot pluggable QSFP28 form factor

Digital diagnostics monitoring (DDM) support

Low power consumption with high reliability

Ideal for long-haul enterprise and telecom networks

Technical Specifications

Specification Value
Form Factor QSFP28
Data Rate 100 Gbps
Transmission Distance 10 km
Wavelength 1270–1330 nm (CWDM)
Connector Type LC duplex
Fiber Type Single Mode Fiber (SMF)
Transmit Power Range –2.7 dBm to +4.5 dBm
Receive Sensitivity –11.5 dBm
Operating Temperature 0C to 70C
Voltage Supply 3.3V

Similar Models Comparison

Model Name Data Rate Wavelength Fiber Type Max Distance Interface
QSFP28 100G LR4 100 Gbps 1270–1330 nm SMF 10 km LC
QSFP28 100G SR4 100 Gbps 850 nm MMF 100 m MPO
QSFP28 100G PSM4 100 Gbps 1310 nm SMF 500 m MPO
QSFP28 100G CWDM4 100 Gbps 1271–1331 nm SMF 2 km LC
QSFP28 100G ER4 100 Gbps 1310 nm SMF 40 km LC
