QSFP28 100G 1310nm 80km Single Mode Fiber Optical Transceiver original new in stock
QSFP28 100G 1310nm 80km Single Mode Fiber Optical Transceiver original new in stock
QSFP28 100G 1310nm 80km Single Mode Fiber Optical Transceiver original new in stock
QSFP28 100G 1310nm 80km Single Mode Fiber Optical Transceiver original new in stock
QSFP28 100G 1310nm 80km Single Mode Fiber Optical Transceiver original new in stock
QSFP28 100G 1310nm 80km Single Mode Fiber Optical Transceiver original new in stock
QSFP28 100G 1310nm 80km Single Mode Fiber Optical Transceiver original new in stock
QSFP28 100G 1310nm 80km Single Mode Fiber Optical Transceiver original new in stock
Specifications
Brand Name :
Hua wei
Model Number :
QSFP28 100G 1310nm
Certification :
CE
Place of Origin :
USA
MOQ :
1pc
Payment Terms :
T/T
Delivery Time :
1-3 working day
Part number :
QSFP28 100G 1310nm
Brief Description :
100G long reach transceiver
Details :
1310nm 80km optical module
Key Features :
QSFP28 single mode fiber
Condition :
Original new
Warranty :
1 year
Packing :
original new
Lead time :
1-3 working day
Ship :
DHL FEDEX UPS
Payment term :
TT in advance
original :
USA
Price :
$35/piece
Description

QSFP28 100G 1310nm 80km Single Mode Fiber Optical Transceiver

Product Overview

The QSFP28 100G 1310 80km SM is a long-reach optical transceiver designed for 100 Gigabit Ethernet transmission over single mode fiber. Operating at the 1310 nm wavelength, it supports data rates of 100 Gbps and enables transmission distances up to 80 kilometers. This module is optimized for metro, enterprise, and telecom applications that require reliable high-speed connectivity over extended distances. It features an LC duplex connector and complies with relevant IEEE and industry standards.

Product Details

Attribute Description
Product Name QSFP28 100G 1310 80km SM
Form Factor QSFP28
Data Rate 100 Gbps
Wavelength 1310 nm
Interface Type LC duplex connector
Fiber Type Single Mode Fiber (SMF)
Max Distance Up to 80 kilometers
Operating Temperature 0C to 70C
Digital Diagnostics Yes
Compatibility IEEE 802.3bs 100G Ethernet standards
Application Metro, enterprise backbone, telecom long haul

Key Features

Supports 100 Gbps data transmission over single mode fiber

Operates at 1310 nm wavelength for long-reach applications

Transmission distance up to 80 km

LC duplex optical interface

Hot pluggable QSFP28 form factor

Digital diagnostics monitoring (DDM) support

High reliability and low power consumption

Ideal for metro, enterprise, and telecom backbone networks

Technical Specifications

Specification Value
Form Factor QSFP28
Data Rate 100 Gbps
Transmission Distance 80 km
Wavelength 1310 nm
Connector Type LC duplex
Fiber Type Single Mode Fiber (SMF)
Transmit Power Range –2 dBm to +3 dBm
Receive Sensitivity –14 dBm
Operating Temperature 0C to 70C
Voltage Supply 3.3V

Similar Models Comparison

Model Name Data Rate Wavelength Fiber Type Max Distance Interface
QSFP28 100G 1310 80km SM 100 Gbps 1310 nm SMF 80 km LC
QSFP28 100G LR4 100 Gbps 1270–1330 nm SMF 10 km LC
QSFP28 100G ER4 100 Gbps 1310 nm SMF 40 km LC
QSFP28 100G SR4 100 Gbps 850 nm MMF 100 m MPO
QSFP28 100G PSM4 100 Gbps 1310 nm SMF 500 m MPO
