CT QDS400SZPTA00 400G QSFP-DD Active Optical Cable For High Speed Data Center
CT QDS400SZPTA00 400G QSFP-DD Active Optical Cable For High Speed Data Center
CT QDS400SZPTA00 400G QSFP-DD Active Optical Cable For High Speed Data Center
CT QDS400SZPTA00 400G QSFP-DD Active Optical Cable For High Speed Data Center
CT QDS400SZPTA00 400G QSFP-DD Active Optical Cable For High Speed Data Center
CT QDS400SZPTA00 400G QSFP-DD Active Optical Cable For High Speed Data Center
CT QDS400SZPTA00 400G QSFP-DD Active Optical Cable For High Speed Data Center
CT QDS400SZPTA00 400G QSFP-DD Active Optical Cable For High Speed Data Center
Specifications
Brand Name :
Hua wei
Model Number :
CT QDS400SZPTA00 400G
Certification :
CE
Place of Origin :
USA
MOQ :
1pc
Payment Terms :
T/T
Delivery Time :
1-3 working day
Price :
$35/piece
Part number :
CT QDS400SZPTA00 400G
Brief Description :
400G QSFP-DD OPEN ZR+
Details :
850nm multimode AOC
Key Features :
400G high speed optical cable
Condition :
Original new
Warranty :
1 year
Packing :
original new
Lead time :
1-3 working day
Ship :
DHL FEDEX UPS
Payment term :
TT in advance
original :
USA
Description
CT QDS400SZPTA00 400G QSFP-DD Active Optical Cable for High-Speed Data Centers
Our stock
T-DQ8FNS-N00 400GBASE-SR8 QSFP-DD 850nm 100m
T-DP4CNH-N00 400GBASE-DR4 QSFP-DD 1310nm 500m
T-DP4CNT-N00 400GBASE-DR4+ QSFP-DD 1310nm 2km
T-DP4CNL-N00 400GBASE-DR4++ QSFP-DD 1310nm 10km
T-DQ4CNT-N00 400GBASE-FR4 QSFP-DD 1310nm 2km
T-DQ4CNL-N00 400GBASE-LR4 QSFP-DD 1310nm 10km
T-DQ4CND-N00 400GBASE-ER4 LITE QSFP-DD 1310nm 30km
CT-QDS400SZRTA00 400G QSFP-DD OIF ZR
CT-QDS400SZPTA00 400G QSFP-DD OPEN ZR+
C-DQ8FNMxxx-N00 400GBASE-AOC QSFP-DD to QSFP-DD 5m

Product Overview

The CT QDS400SZPTA00 is a 400G QSFP-DD active optical cable (AOC) designed for high-speed, high-density, short-reach interconnects within data centers. It offers a reliable plug-and-play solution for 400 Gigabit Ethernet connectivity between QSFP-DD ports without the need for external transceivers or fiber optic patch cords. Utilizing multimode fiber and integrated optical transceivers, this AOC provides superior signal integrity and low power consumption, making it ideal for high-performance computing (HPC), cloud infrastructure, and enterprise data center applications.

Product Details

Attribute Description
Product Name CT QDS400SZPTA00
Cable Type Active Optical Cable (AOC)
Form Factor QSFP-DD to QSFP-DD
Data Rate 400 Gbps
Transmission Speed 8 x 50 Gbps PAM4
Wavelength 850 nm
Fiber Type Multimode OM3/OM4
Cable Length Factory-configured (typically from 1 to 30 meters)
Connector Type QSFP-DD
Application Data center, cloud computing, HPC, switch-to-switch links
Operating Temperature 0C to 70C

Key Features

400G QSFP-DD to QSFP-DD active optical cable

Supports 8-channel PAM4 transmission at 50 Gbps per lane

Plug-and-play deployment, no external optics required

850 nm VCSEL-based transmission over multimode fiber

Optimized for short-reach connections (1–30 meters)

Lightweight, flexible, and EMI-immune

Hot-pluggable QSFP-DD form factor

Ideal for rack-to-rack, spine-to-leaf, and aggregation layer deployments

Technical Specifications

Specification Value
Form Factor QSFP-DD
Cable Type AOC (Active Optical Cable)
Data Rate 400 Gbps (8 x 50 Gbps PAM4)
Transmission Distance Up to 30 meters (typical)
Wavelength 850 nm
Connector Type QSFP-DD
Fiber Type Multimode OM3/OM4
Power Consumption < 10W per end
Operating Temperature 0C to 70C
EMI Immunity Excellent
Compliance IEEE 802.3bs, QSFP-DD MSA

Similar Models Comparison

Model Name Interface Type Data Rate Max Distance Connector
CT QDS400SZPTA00 QSFP-DD to QSFP-DD AOC 400 Gbps 30 m QSFP-DD
QSFP-DD DAC 400G QSFP-DD to QSFP-DD DAC 400 Gbps 3 m QSFP-DD
CT QDD400-LR4 QSFP-DD Optical 400 Gbps 10 km LC Duplex
QSFP-DD AOC-5M QSFP-DD to QSFP-DD AOC 400 Gbps 5 m QSFP-DD
