Specifications
Brand Name :
Hua wei
Model Number :
T DQ4CNL N00
Certification :
CE
Place of Origin :
USA
MOQ :
1pc
Payment Terms :
T/T
Delivery Time :
1-3 working day
Price :
$35/piece
Part number :
T DQ4CNL N00
Brief Description :
400GBASE-LR4 QSFP-DD 1310nm 10km
Details :
25G SFP28 passive cable
Key Features :
low latency passive copper interconnect
Condition :
Original new
Warranty :
1 year
Packing :
original new
Lead time :
1-3 working day
Ship :
DHL FEDEX UPS
Payment term :
TT in advance
original :
USA
Description
T DQ4CNL N00 100G QSFP28 to 4x 25G SFP28 DAC Breakout Cable for Data Centers
Our stock
T-DQ8FNS-N00 400GBASE-SR8 QSFP-DD 850nm 100m
T-DP4CNH-N00 400GBASE-DR4 QSFP-DD 1310nm 500m
T-DP4CNT-N00 400GBASE-DR4+ QSFP-DD 1310nm 2km
T-DP4CNL-N00 400GBASE-DR4++ QSFP-DD 1310nm 10km
T-DQ4CNT-N00 400GBASE-FR4 QSFP-DD 1310nm 2km
T-DQ4CNL-N00 400GBASE-LR4 QSFP-DD 1310nm 10km
T-DQ4CND-N00 400GBASE-ER4 LITE QSFP-DD 1310nm 30km
CT-QDS400SZRTA00 400G QSFP-DD OIF ZR
CT-QDS400SZPTA00 400G QSFP-DD OPEN ZR+
C-DQ8FNMxxx-N00 400GBASE-AOC QSFP-DD to QSFP-DD 5m

Product Overview

The T DQ4CNL N00 is a 100G QSFP28 to 4x 25G SFP28 passive direct attach copper (DAC) breakout cable, optimized for short-reach, high-density data center interconnects. This high-performance, cost-effective solution enables 1-to-4 breakout connectivity from a single 100G QSFP28 port to four individual 25G SFP28 ports. Designed with low-latency and zero power consumption, it is ideal for Top-of-Rack (ToR) switch-to-server, network aggregation, and high-performance computing (HPC) applications.

Product Details

Attribute Description
Product Name T DQ4CNL N00
Cable Type Passive Direct Attach Copper Cable (DAC)
Form Factor QSFP28 to 4 x SFP28
Data Rate 100 Gbps total (4 x 25 Gbps)
Transmission Speed 25 Gbps per channel
Interface Type 1 x QSFP28 ↔ 4 x SFP28
Cable Length Factory-defined (commonly 0.5 m to 3 m based on code suffix)
Conductor Type Twinax copper
Application ToR switch breakout, data center, HPC, server NIC connections
Operating Temperature 0C to 70C

Key Features

QSFP28 to 4x SFP28 passive copper breakout

Supports 100G Ethernet split into 4x 25G channels

Hot-pluggable, MSA-compliant

Plug-and-play setup, no optical transceivers required

Ideal for short-reach, in-rack connections

Low power and ultra-low latency performance

EMI shielding for high-signal integrity

RoHS compliant and environmentally friendly

Technical Specifications

Specification Value
Interface QSFP28 to 4 x SFP28
Total Data Rate 100 Gbps
Channel Speed 25 Gbps each
Cable Type Passive Copper DAC
Length Options Typically 0.5 m, 1 m, 2 m, 3 m
Connector Type QSFP28 / SFP28
Conductor Material Twinax copper
Operating Temperature 0C to 70C
Compliance SFF-8636, QSFP28/SFP28 MSA
RoHS Compliance Yes

Similar Models Comparison

Model Name Interface Type Data Rate Max Length Application
T DQ4CNL N00 QSFP28 to 4x SFP28 Passive DAC 100G 3 m Switch-to-server breakout
T DQ4CND N00 QSFP28 to 4x SFP28 Passive DAC 100G 3 m High-density aggregation
QSFP28-AOC-4SFP28 QSFP28 to 4x SFP28 AOC 100G Up to 30 m Rack-to-rack optical link
QSFP28-4SFP28-1M QSFP28 to 4x SFP28 Passive DAC 100G 1 m ToR switch breakout
