QSFP28 100G PSM4 1310nm 500m Optical Transceiver For Parallel SMF
QSFP28 100G PSM4 1310nm 500m Optical Transceiver For Parallel SMF
QSFP28 100G PSM4 1310nm 500m Optical Transceiver For Parallel SMF
QSFP28 100G PSM4 1310nm 500m Optical Transceiver For Parallel SMF
QSFP28 100G PSM4 1310nm 500m Optical Transceiver For Parallel SMF
QSFP28 100G PSM4 1310nm 500m Optical Transceiver For Parallel SMF
QSFP28 100G PSM4 1310nm 500m Optical Transceiver For Parallel SMF
QSFP28 100G PSM4 1310nm 500m Optical Transceiver For Parallel SMF
Specifications
Brand Name :
Hua wei
Model Number :
QSFP28 100G PSM4
Certification :
CE
Place of Origin :
USA
MOQ :
1pc
Payment Terms :
T/T
Delivery Time :
1-3 working day
Price :
$35/piece
Part number :
QSFP28 100G PSM4
Brief Description :
data center 100G PSM4
Details :
telecom 100G MPO module
Key Features :
QSFP28 parallel optics
Condition :
Original new
Warranty :
1 year
Packing :
original new
Lead time :
1-3 working day
Ship :
DHL FEDEX UPS
Payment term :
TT in advance
original :
USA
Description

QSFP 100G ER4 1310nm 40km Optical Transceiver for Extended Reach Ethernet

Product Overview

The QSFP28 100G PSM4 is a high-speed optical transceiver module designed for 100 Gigabit Ethernet parallel single mode fiber applications. Operating in the 1310 nm wavelength range, it transmits data over four parallel fibers, each carrying 25 Gbps, to achieve an aggregate rate of 100 Gbps. The module supports transmission distances up to 500 meters over single mode fiber using MPO connectors. It is ideal for data centers, telecom, and high-performance computing environments requiring cost-effective and efficient 100G connectivity over moderate distances.

Product Details

Attribute Description
Product Name QSFP28 100G PSM4
Form Factor QSFP28
Data Rate 100 Gbps (4 x 25 Gbps)
Wavelength 1310 nm
Interface Type MPO
Fiber Type Single Mode Fiber (SMF)
Max Distance Up to 500 meters
Operating Temperature 0C to 70C
Digital Diagnostics Yes
Compatibility IEEE 802.3bm 100GBASE-PSM4
Application Data center, telecom, high-performance computing

Key Features

100 Gbps data transmission via 4 parallel 25 Gbps channels

Operates at 1310 nm wavelength over single mode fiber

Supports up to 500 meters transmission distance

MPO optical connector for parallel fiber connections

Hot pluggable QSFP28 form factor

Digital diagnostics monitoring (DDM)

Cost-effective solution for 100G Ethernet connectivity

Ideal for data center interconnect and telecom applications

Technical Specifications

Specification Value
Form Factor QSFP28
Data Rate 100 Gbps
Transmission Distance 500 m
Wavelength 1310 nm
Connector Type MPO
Fiber Type Single Mode Fiber (SMF)
Transmit Power Range –4 dBm to +4 dBm
Receive Sensitivity –12 dBm
Operating Temperature 0C to 70C
Voltage Supply 3.3V

Similar Models Comparison

Model Name Data Rate Wavelength Fiber Type Max Distance Interface
QSFP28 100G PSM4 100 Gbps 1310 nm SMF 500 m MPO
QSFP28 100G LR4 100 Gbps 1270–1330 nm SMF 10 km LC
QSFP28 100G SR4 100 Gbps 850 nm MMF 100 m MPO
QSFP28 100G CWDM4 100 Gbps 1271–1331 nm SMF 2 km LC
QSFP28 100G ER4 100 Gbps 1310 nm SMF 40 km LC
