Data Centers C DQ8FNMxxx N00 400G QSFP-DD To 8x 50G SFP56 Passive DAC Cable
Data Centers C DQ8FNMxxx N00 400G QSFP-DD To 8x 50G SFP56 Passive DAC Cable
Data Centers C DQ8FNMxxx N00 400G QSFP-DD To 8x 50G SFP56 Passive DAC Cable
Data Centers C DQ8FNMxxx N00 400G QSFP-DD To 8x 50G SFP56 Passive DAC Cable
Data Centers C DQ8FNMxxx N00 400G QSFP-DD To 8x 50G SFP56 Passive DAC Cable
Data Centers C DQ8FNMxxx N00 400G QSFP-DD To 8x 50G SFP56 Passive DAC Cable
Data Centers C DQ8FNMxxx N00 400G QSFP-DD To 8x 50G SFP56 Passive DAC Cable
Data Centers C DQ8FNMxxx N00 400G QSFP-DD To 8x 50G SFP56 Passive DAC Cable
Specifications
Brand Name :
Hua wei
Model Number :
C DQ8FNMxxx N00 400G
Certification :
CE
Place of Origin :
USA
MOQ :
1pc
Payment Terms :
T/T
Delivery Time :
1-3 working day
Price :
$35/piece
Part number :
C DQ8FNMxxx N00 400G
Brief Description :
400GBASE-AOC QSFP-DD to QSFP-DD 5m
Details :
400G breakout cable
Key Features :
400G DAC cable
Condition :
Original new
Warranty :
1 year
Packing :
original new
Lead time :
1-3 working day
Ship :
DHL FEDEX UPS
Payment term :
TT in advance
original :
USA
Description
C DQ8FNMxxx N00 400G QSFP-DD to 8x 50G SFP56 Passive DAC Cable for Data Centers
Our stock
T-DQ8FNS-N00 400GBASE-SR8 QSFP-DD 850nm 100m
T-DP4CNH-N00 400GBASE-DR4 QSFP-DD 1310nm 500m
T-DP4CNT-N00 400GBASE-DR4+ QSFP-DD 1310nm 2km
T-DP4CNL-N00 400GBASE-DR4++ QSFP-DD 1310nm 10km
T-DQ4CNT-N00 400GBASE-FR4 QSFP-DD 1310nm 2km
T-DQ4CNL-N00 400GBASE-LR4 QSFP-DD 1310nm 10km
T-DQ4CND-N00 400GBASE-ER4 LITE QSFP-DD 1310nm 30km
CT-QDS400SZRTA00 400G QSFP-DD OIF ZR
CT-QDS400SZPTA00 400G QSFP-DD OPEN ZR+
C-DQ8FNMxxx-N00 400GBASE-AOC QSFP-DD to QSFP-DD 5m

Product Overview

The C DQ8FNMxxx N00 is a high-density direct attach cable (DAC) assembly, designed to support 400G QSFP-DD to 8x 50G SFP56 breakout configurations. This passive copper cable solution provides a cost-effective, low-latency, and energy-efficient interconnect for high-speed data center environments. It enables direct point-to-multipoint connectivity between 400G switches and multiple 50G server NICs without the need for optical transceivers.

Product Details

Attribute Description
Product Name C DQ8FNMxxx N00
Cable Type Passive Direct Attach Cable (DAC)
Connector 1 QSFP-DD
Connector 2 8 x SFP56
Data Rate 400G (1x400G ↔ 8x50G breakout)
Interface Type QSFP-DD to 8x SFP56
Cable Length xxx meters (e.g. 010 = 1m, 020 = 2m, etc.)
Transmission Speed 50 Gbps per lane
Conductor Twinax copper
Application Data center switch-to-server breakout, high-speed short links
Operating Temperature 0C to 70C

Key Features

QSFP-DD to 8x SFP56 passive copper breakout cable

Supports 400G (8x 50G PAM4) Ethernet applications

Ideal for TOR (Top-of-Rack) switch-to-server connections

Low power, low latency, and low cost alternative to optical links

Plug-and-play deployment for high-density environments

Compliant with QSFP-DD and SFP56 MSA standards

Technical Specifications

Specification Value
Interface QSFP-DD to 8 x SFP56
Data Rate 400 Gbps total (8 x 50 Gbps)
Signal Type PAM4
Cable Type Passive Twinax Copper
Length Options 0.5m, 1m, 2m, 3m (denoted by xxx)
Connector Type QSFP-DD / SFP56
Operating Temperature 0C to 70C
RoHS Compliance Yes
Application Use Case Switch-to-server high-speed links

Similar Models Comparison

Model Interface Data Rate Max Length Cable Type Use Case
C DQ8FNM010 N00 QSFP-DD to 8x SFP56 400G 1m Passive Copper DAC Short-reach breakout
C DQ8FNM020 N00 QSFP-DD to 8x SFP56 400G 2m Passive Copper DAC Top-of-rack connectivity
QSFP-DD-2xQSFP56 QSFP-DD to 2x QSFP56 400G 3m Passive Copper DAC Switch-to-switch
QSFP-DD-to-QSFP-DD QSFP-DD to QSFP-DD 400G 2m Passive Copper DAC Direct 400G link
