Specifications
Brand Name :
Hua wei
Model Number :
QSFP28 100G SR4 MPO
Certification :
CE
Place of Origin :
USA
MOQ :
1pc
Payment Terms :
T/T
Delivery Time :
1-3 working day
Price :
$35/piece
Part number :
QSFP28 100G SR4 MPO
Brief Description :
QSFP28 MPO 100G
Details :
100G Ethernet MMF module
Key Features :
data center 100G fiber
Condition :
Original new
Warranty :
1 year
Packing :
original new
Lead time :
1-3 working day
Ship :
DHL FEDEX UPS
Payment term :
TT in advance
original :
USA
Description
QSFP 40G LR4 1310nm 10km Optical Transceiver for Long Distance Fiber

Product Overview

The QSFP28 100G SR4 is a high-speed optical transceiver module designed for 100 Gigabit Ethernet short-reach applications over multimode fiber. It transmits 4 x 25 Gbps signals in parallel using an 850 nm wavelength, offering a total data rate of 100 Gbps. With an MPO/MTP interface, this transceiver supports distances up to 70 meters over OM3 fiber and 100 meters over OM4 fiber. It is ideal for high-density data center environments, cloud computing platforms, and enterprise network backbones.

Product Details

Attribute Description
Product Name QSFP28 100G SR4
Form Factor QSFP28
Data Rate 100 Gbps (4 x 25 Gbps)
Wavelength 850 nm
Interface Type MPO/MTP
Fiber Type Multimode Fiber (OM3, OM4)
Max Distance 70 m (OM3), 100 m (OM4)
Operating Temperature 0C to 70C
Digital Diagnostics Yes
Compatibility IEEE 802.3bm 100GBASE-SR4
Application Data center, cloud network, enterprise LAN switch uplinks

Key Features

100 Gbps aggregated data rate using 4 parallel 25 Gbps channels

Operates over 850 nm wavelength

MPO/MTP optical connector for parallel multimode fiber

Supports up to 70 m on OM3, 100 m on OM4

Hot pluggable QSFP28 form factor

Digital diagnostics monitoring (DDM)

Low power consumption, high performance

Ideal for top-of-rack and spine-leaf architectures

Technical Specifications

Specification Value
Form Factor QSFP28
Data Rate 100 Gbps
Transmission Distance 70 m (OM3), 100 m (OM4)
Wavelength 850 nm
Connector Type MPO/MTP
Fiber Type Multimode Fiber (MMF)
Transmit Power Range –8.4 dBm to +2.4 dBm
Receive Sensitivity –10.3 dBm
Operating Temperature 0C to 70C
Voltage Supply 3.3V

Similar Models Comparison

Model Name Data Rate Wavelength Fiber Type Max Distance Interface
QSFP28 100G SR4 100 Gbps 850 nm MMF 100 m MPO
QSFP28 100G LR4 100 Gbps 1310 nm SMF 10 km LC
QSFP28 100G PSM4 100 Gbps 1310 nm SMF 500 m MPO
QSFP28 100G CWDM4 100 Gbps 1271–1331 nm SMF 2 km LC
QSFP28 100G ER4 100 Gbps 1310 nm SMF 40 km LC
