QSFP 40G SR4 850nm MPO Transceiver SFP Modules For 100m Multimode Fiber
QSFP 40G SR4 850nm MPO Transceiver SFP Modules For 100m Multimode Fiber
QSFP 40G SR4 850nm MPO Transceiver SFP Modules For 100m Multimode Fiber
QSFP 40G SR4 850nm MPO Transceiver SFP Modules For 100m Multimode Fiber
QSFP 40G SR4 850nm MPO Transceiver SFP Modules For 100m Multimode Fiber
QSFP 40G SR4 850nm MPO Transceiver SFP Modules For 100m Multimode Fiber
QSFP 40G SR4 850nm MPO Transceiver SFP Modules For 100m Multimode Fiber
QSFP 40G SR4 850nm MPO Transceiver SFP Modules For 100m Multimode Fiber
Specifications
Brand Name :
Hua wei
Model Number :
QSFP 40G SR4 850nm
Certification :
CE
Place of Origin :
USA
MOQ :
1pc
Payment Terms :
T/T
Delivery Time :
1-3 working day
Price :
$35/piece
Part number :
QSFP 40G SR4 850nm
Brief Description :
MPO 40G optical transceiver
Details :
multimode QSFP 40G
Key Features :
data center 40G module
Condition :
Original new
Warranty :
1 year
Packing :
original new
Lead time :
1-3 working day
Ship :
DHL FEDEX UPS
Payment term :
TT in advance
original :
USA
Description
QSFP 40G SR4 850nm MPO Transceiver for 100m Multimode Fiber

Product Overview

The QSFP 40G SR4 is a high-speed optical transceiver module designed for 40 Gigabit Ethernet short-reach applications over multimode fiber. It operates at an 850 nm wavelength using four independent full-duplex channels, each capable of 10 Gbps, delivering an aggregate bandwidth of 40 Gbps. The module supports transmission distances of up to 100 meters on OM3 and 150 meters on OM4 multimode fiber, making it ideal for data center interconnects, top-of-rack switching, and enterprise backbone links.

Product Details

Attribute Description
Product Name QSFP 40G SR4
Form Factor QSFP+
Data Rate 40 Gbps (4 x 10 Gbps)
Wavelength 850 nm
Interface Type MPO/MTP multimode connector
Fiber Type Multimode Fiber (OM3/OM4)
Max Distance 100 m (OM3), 150 m (OM4)
Operating Temperature 0C to 70C
Digital Diagnostics Yes
Compatibility IEEE 802.3ba 40GBASE-SR4
Application Data centers, high-performance computing, cloud networking

Key Features

4-channel full-duplex transceiver module

Total 40 Gbps aggregate bandwidth over multimode fiber

Transmission distance up to 150 meters on OM4

MPO/MTP optical connector for high-density cabling

Hot pluggable QSFP+ form factor

Digital diagnostics monitoring (DDM) support

Low power consumption and high port density

Ideal for 40G Ethernet backbone and aggregation links

Technical Specifications

Specification Value
Form Factor QSFP+
Data Rate 40 Gbps
Transmission Distance 100 m (OM3), 150 m (OM4)
Wavelength 850 nm
Connector Type MPO/MTP
Fiber Type Multimode Fiber (MMF)
Transmit Power Range –7.5 dBm to 0 dBm
Receive Sensitivity –9.5 dBm
Operating Temperature 0C to 70C
Voltage Supply 3.3V

Similar Models Comparison

Model Name Data Rate Wavelength Fiber Type Max Distance Interface
QSFP 40G SR4 40 Gbps 850 nm MMF 150 m MPO
QSFP 40G LR4 40 Gbps 1310 nm SMF 10 km LC
QSFP 40G PSM4 40 Gbps 1310 nm SMF 500 m MPO
QSFP 40G ER4 40 Gbps 1310 nm SMF 40 km LC
QSFP 40G BiDi 40 Gbps 850 nm MMF 100 m LC

QSFP 40G SR4 850nm MPO Transceiver SFP Modules For 100m Multimode Fiber

Sinanova specializes in supplying ICT networking equipment from leading brands such as Cisco, Huawei, and Juniper. Our product range includes switches, routers, firewalls, wireless access points and controllers, IP phones, video conferencing solutions, and more. We are committed to delivering original and reliable hardware along with professional ICT solutions—all at competitive prices. Our high-quality service ensures a smooth and hassle-free purchasing experience for our clients.
