WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
Specifications
Model NO. :
WIND-AC-CW001
Specification :
Middle Size
Trademark :
Wind Automation
Origin :
China
HS Code :
8479811000
Production Capacity :
100 Sets/Year
Description
Miyachi Welding Power Commutator Hot Stacking Machine
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
The machine adapts AC pulse. The whole machine is controlled by MITSUBISHI PLC; it could control the exact pre-pressing /welding /transposition /hold time effectively. The operation is free from interference.

(1)Specification
Voltage 230V
Rated frequency 50-60Hz
Rated power 25KVA
Wire diameter 0.06-1.6 mm
Armature OD 0-100mm
Commutator OD 0-60mm
Stack length 0-350mm
Air source 0.3~0.5Mp
Cooling method Water cooling and air cooling

(2)Application
The machine is used for the starter of cars and motorcycle, DC motors, power tool motors, household appliances motors and series motors.

(3)Operation
1)Connect machine to air source and power supply.
2)Switch the button to Miyachi.
3)Turn on machine power switch.
4)Switch the two buttons under the touch screen to "Auto" and "Run" .
5)Switch the rough set to 2 and the accurate set to 8.
6) Power on Miyachi.
7) Press "Stop" button. Then press the "Start" button to begin fusing.


WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
WIND-AC-CW001 Miyachi Welding Power Commutator Hot Stacking Machine with Middle Size
