630A 20kA MV Circuit Breaker 12kV 24kV Outdoor VCB Breaker Compact
630A 20kA MV Circuit Breaker 12kV 24kV Outdoor VCB Breaker Compact
Specifications
Brand Name :
MacweyTEK
Model Number :
ZW32-12
Certification :
IEC Type Test Report
Place of Origin :
China
MOQ :
1 pc
Price :
$800-$2000
Payment Terms :
T/T
Supply Ability :
4000 pcs
Delivery Time :
15 days
Packaging Details :
wooden case
Name :
MV Circuit Breaker
Description

12kv 24kv outdoor vacuum circuit breaker high voltage outdoor recloser


ZW32-12 outdoor vacuum cicuit breaker (hereinafter referred to as circuit breaker) is
an outdoor power distribution equipment with a rated voltage of 12kV and three-phase AC
50Hz.Mainly used for breaking and closing the load curent,overload curent and
short circuit curent in the power system.It is suitable for protection and control
in substations and industrial and mining enterprise power distribution systems,
and places where rural power grids are frequently operated.
The circuit breaker has the characteristics of smallsize,light weight,anti-condensation,
maintenance-free,etc.,and can adapt to harsh weather conditions and dirty
environments.


Environmental conditions
◆ Ambient temperature:not higher than+40℃,not lower than-40℃;
◆ Relative humidity of air:daily average value is not greater than 95%,monthly average value is not greater than 90%;
◆ Altitude does not exceed 2000 meters;
◆Wind pressure does not exceed 700Pa(equivalent to wind speed 34m/s);
◆ The seismic intensity does not exceed 8;
◆No fire,explosion,severe pollution,chemical corrosion and violent vibration.



he main technical parameters

Project

Unit

Parameter

Rated voltage

kV

12

Rated frequency

Hz

50

Rated current

A

630

Rated short-circuit breaking current

kA

20

Rated peak withstand current(peak value)

kA

50

Rated short-time withstand current

kA

20

Rated short-circuit making current (peak value)

kA

50

Mechanical life

Times

10000

Breaking times of rated short-circuit breaking current

Times

30

Power frequency withstand voltage(1min):(wet)(dry)interphase,ground /fracture

kV

42/48

Lightning impulse withstand voltage (peak)interphase,ground/fracture

kV

75/85

Secondary circuit 1min power frequency withstand voltage

kV

2
