10kv 12kv outdoor high-voltage three-phase permanent magnet fast vacuum circuit breaker

Overview
AB-3S-12 series outdoor high-voltage three-phase permanent magnet vacuum cicuit breaker is a new generation

of the latest generation of the company's comprehensive domestic and foreign advanced technology,the strengths

of the public Inteligent vacuum circuit breaker.This product can be used as a switch for the 10kV side and

10kv outlet of the main transformer of the 35kV substation,and can also be used as a pole switch on the

distribution network.It can be easily controlled,protected,combined with various control units produced

by our company.Star survey and communication are the first choice equipment for realizing distribution

network automation and miniaturization.

Operating environmental conditions
◆Working environment temperature:no more than 40℃;daily average temperature does not exceed 35℃;minimum ambient air temperature is -25℃;
◆ Air relative humidity:daily average value is not greater than 95%,monthly average value is not greater than 90%;daily average value of water vapor pressure is not greater than 2.2kPa;monthly average value is not greater than 1.8kPa;
◆ Altitude:no more than 2000m;
◆The surrounding area is not obviously polluted by dust,smoke,corrosive and/or flammable gas,steam or salt spray;
◆Vibration or ground motion from outside of switchgear and control equipment can be ignored;
◆ The amplitude of induced electromagnetic interference in the secondary system does not exceed 1.6kV

The Main Technical Parameters
