12kV 630A 20kA Vacuum Circuit Breakers Permanent Magnet Compact Circuit Breaker
12kV 630A 20kA Vacuum Circuit Breakers Permanent Magnet Compact Circuit Breaker
Specifications
Brand Name :
Macwey
Model Number :
MSS
MOQ :
1
Price :
$1500
Payment Terms :
T/T
Supply Ability :
2000
Delivery Time :
20 days
Packaging Details :
wooden
Name :
Vacuum Circuit Breakers
Rated voltage :
12 kV
Rated current :
630A
Rated frequency :
50Hz
Power frequency withstand voltage :
43kV
Lightning Impulse Withstand Voltage :
85kV
Description

12kv MSS Tavriad permanent magnet vacuum circuit breaker 630A 20kA


This circuit breaker is the same to Tavrida, with permanent mangent structure, compact size.

Widely used in site places which require frequent operations and frequent breaking short circuit current.

The performance is extremely stable, and mechanical life could be up to 50000 times, and weight less than 50kgs.


Item Unit
Rated voltage kV 12
Rated current A 630
Rated frequency Hz 50
Power frequency withstand voltage kV 43
Lightning Impulse Withstand Voltage kV 85
Short-Circuit Breaking Current kA 20
Rated Short-Circuit Making Current kA 50
Rated Short-Time Withstand Current kA 20
Rated Short-Time Duration s 4
Rated Peak Withstand Current kA 50
Rated transfer current A /
Rated Operating sequence / O-0.3s-CO-15s-CO
Mechanical life times 50000
