Specifications
Model Number :
HBF80-17NH
Range of Applications :
Industrial
Type :
Electric Holding Furnace
Usage :
Sintering
Fuel :
Electric
Effective Chamber Dimensions :
400*400*500mm(W*H*D)
Atmosphere :
Nitrogen/Hydrogen
Transport Package :
Wooden Package
Specification :
1570*2050*1830mm (W*H*D)
Trademark :
Chitherm
Origin :
China
HS Code :
8514101000
Supply Ability :
Customized
Customization :
Available
Certification :
ISO
Place Style :
Vertical
Place of Origin :
China
Brand Name :
Chitherm
MOQ :
1
Price :
Negotiable
Packaging Details :
Customized
Delivery Time :
Customized
Payment Terms :
Customized
Description
1700 ordm C Hbf80-17nh Type Temperature Atmosphere Box Furnace with Effective Chamber Dimensions 400*400*500mm W*H*D
1. Applications:
It is used for high-temperature sintering of HTCC packaging shells in a nitrogen + wet hydrogen atmosphere, and can also be applied for high-temperature sintering of zirconia, alumina, oxygen sensors, and ITO targets in an air atmosphere.

2. Mainly Specifics:
  1. Rated Temp.: 1600ºC
  2. Max Temp.: 1700ºC
  3. Effective Dimensions: 400 × 400 × 500mm(W×H×D)
  4. Heating Method: U-shaped molybdenum coil
  5. Process Atmosphere: nitrogen/hydrogen (optional humidification function)
  6. Temperature Control Stability: ±1ºC, with PID parameter self-tuning function
  7. Temperature Uniformity: better than ±5ºC (1600ºC insulation 2 small time and space furnace test)
  8. Thermocouple: B Type
  9. Temperature control points: 1
  10. Number of Temp. Profiles: 19×19 (the temperature controller can save 19 profiles, each profile can be set 19 steps)
  11. Exhaust: One exhaust port with ignition device
  12. Alarm System: over temperature, thermocouple failure and other abnormal conditions will activate sound and light alarm protection, over temperature heating power will turn off automatically
  13. Max Heating Power: 25kW
  14. Insulation Power: ≤15kW
  15. Heating Rate: RT - 1000ºC ≤ 5ºC/min, 1000 - 1600ºC ≤ 2ºC/min
  16. Surface Temperature Rise: < 35ºC
  17. Weight: about 1600kg
1700 Ordm C Electric Atmosphere High Temperature Box Furnace Heat Treatment 1600kg
1700 Ordm C Electric Atmosphere High Temperature Box Furnace Heat Treatment 1600kg
3. Delivery List
Item Note QTY
Basic Compositions Furnace 1 PC
Certificates of Inspection Furnace and major purchased components 1 Set
Technical Documents Furnace specifications, technical documents of major purchased components, etc 1 Set
Key Parts Heating Elements Molybdenum Coil 1 Set
Thermocouple Watlow, THERMOWAY, B Type 1 PC
Temperature Controller CHINO 1 Set
Monitor Proface 10" touch screen 1 Set
Vacuum Pump VALUE, 100m³/h 1 Set
Oxygen Analyzer CHANG'AI 1 Set
Mass Flowmeter HORIBA 2 Sets
Flow Indicator HORIBA 2 Sets
Dew Point Probe VAISALA 1 Set
Spares Heating Elements Molybdenum Coil 1 PC

5. Facility Requirements
5.1 Environmental conditions: Temperature 0 - 40ºC, humidity ≤ 80% RH, no corrosive gas, no strong
airflow disturbance.
5.2 Process air conditions: nitrogen, purity 99.999%, air source pressure 0.2 - 0.4Mpa, gas
consumption 3 - 6m3 /h; Hydrogen, purity 99.99%, gas source pressure not less than 0.1Mpa, gas consumption is 0.6 - 6m3 /h;
5.3 Power air source conditions: clean, dry, oil-free compressed air, pressure 0.4 - 0.8Mpa;
5.4 Water Inlet condition: 0.1 - 0.3Mpa, clean, no corrosion, supply flow 2 - 5L/min;
5.5 Ventilation system: non-contact access to the user pumping system, pumping capacity is greater
than 10m3 /h;
5.6 Power conditions: capacity greater than 35kVA, 3 phases 5 lines, voltage 220/380V, frequency
50Hz(according to local situation). Live wire: yellow, green, red, neutral wire: blue, ground wire: yellow-green;
5.7 Installation site: 2500mm×3000mm×2500mm (W×H×D), installation area greater than 7m2.
