Specifications
Model NO. :
HRF216-05N
Range of Applications :
Industrial
Type :
Electric Holding Furnace
Usage :
Ceramic Drying
Atmosphere :
Nitrogen
Effective Chamber Dimensions :
600*600*600mm(W*H*D)
Rated Temp. :
350ºC
Max Temp. :
500ºC
Transport Package :
Wooden Packaging
Specification :
1350*1750*1950mm(W*H*D)
Trademark :
Chitherm
Origin :
China
HS Code :
8514101000
Supply Ability :
Customized
Customization :
Available
Certification :
ISO
Place Style :
Vertical
Place of Origin :
China
Brand Name :
Chitherm
MOQ :
1
Price :
Negotiable
Packaging Details :
Customized
Delivery Time :
Customized
Payment Terms :
Customized
Description

Effective Dimensions 600*600*600mm W*H*D Nitrogen Atmosphere Ceramic Drying Oven for High Temperature Drying Hrf216-05n

1. Applications:

Mainly used for binder burning out(BBO) process of electronic components, ceramic substrates.

2. Mainly Specifics:

  1. Rated Temp.: 350ºC
  2. Max Temp.: 500ºC
  3. Effective Dimensions: 600 × 600 × 600mm(W×H×D)
  4. Heating Method: Stainless Steel Heater
  5. Process Atmosphere: Nitrogen
  6. Temperature Control Stability: ±1ºC, with PID parameter self-tuning function
  7. Temperature Uniformity: better than ±5ºC (insulation 1 hour at 400ºC test)
  8. Thermocouple: Type K
  9. Temperature control points: 1
  10. Temperature measurement points: 1 point
  11. Process Steps: 4 × 10 steps
  12. Exhaust: One exhaust port on top
  13. Alarm System: over temperature, thermocouple failure and other abnormal conditions will activate sound and light alarm protection
  14. Max Heating Power: 18kW
  15. Insulation Power: ≤ 12kW
  16. Surface Temperature Rise: ≤ 35ºC
  17. Weight: about 900kg
  18. Furnace Dimensions: about 1350×1750×21950mm (W×H×D);
  19. Appearance Color: light gray
18kW Nitrogen Reducing Atmosphere Furnace Ceramic Drying Oven Heat Treatment Gas Furnace18kW Nitrogen Reducing Atmosphere Furnace Ceramic Drying Oven Heat Treatment Gas Furnace
3. Delivery List
Item Note QTY
Basic Compositions Dryer 1 PC
Certificates of Inspection Dryer and major purchased components 1 Set
Technical Documents Manual instructions, technical documents of major purchased components, etc 1 Set
Key Parts Heating Elements Stainless Steel Heater 1 Set
Thermocouple WATLOW/THERMOWAY, Type K 1 PC
Temperature Controller 1 Set
Monitor Touch screen 1 Set
Spares SSR 1 PC

4. Facility Requirements
4.1 Environmental conditions: Temperature 0 - 40ºC, humidity ≤ 80% RH, no corrosive gas, no strong
airflow disturbance.
4.2 Process air conditions: 99.999% purity nitrogen, pressure 0.2 - 0.4Mpa, gas consumption 10m3 /h.
4.3 Ventilation system: non-contact access to the user pumping system, pumping capacity is greater
than 15m3 /h;
4.4 Ground requirements: level, no obvious vibration, bearing capacity >300Kg/m2 .
4.5 Power conditions: capacity greater than 24kVA, 3 phases 5 lines, voltage 220/380V, frequency
50Hz(according to local situation). Live wire: yellow, green, red, neutral wire: blue, ground wire: yellow-green;
4.6 Installation site: 2000mm×3000mm×3000mm (W*H*D), installation area greater than 6m2.
