Specifications
Brand Name :
Chitherm
Model Number :
HBF105-14
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
Customized
Supply Ability :
50 Sets/Year
Delivery Time :
Customized
Packaging Details :
Customized
Range of Applications :
Industrial
Type :
Electric Holding Furnace
Usage :
Steel Molding
Fuel :
Electric
Effective Chamber Dimensions :
400*330*800mm(W*H*D)
Setter Plate :
Corundum-Mullite
Transport Package :
Wooden Package
Specification :
850*900*1200mm (W*H*D)
Trademark :
Chitherm
Origin :
China
HS Code :
8514101000
Customization :
Available
Certification :
ISO
Place Style :
Vertical
Description

HBF105-14 Simple Operation Atmosphere Box Furnace High Uniformity Atmosphere Box FurnaceI. Equipment Overview
Model: HBF105-14 Sintering Furnace
Key Features:

  • Silicon molybdenum heating elements (acid/alkali-resistant, excellent uniformity)
  • Simple operation, suitable for labs and small-batch production
  • Integrated intelligent control with heating/cooling control cabinet

II. Technical Specifications
Item | Parameter
Operating Temperature | 1300°C (Max tested: 1500°C)
Chamber Dimensions (W×H×D) | 400×330×800mm
Boat Material | Corundum mullite
Temperature Stability | ±1°C
Temperature Uniformity | ±5°C
Programmable Segments | 40 segments
Safety Alarms | Overheat/thermocouple failure/low pressure audio-visual alarms; heating-door interlock
Surface Temperature Rise | ＜35°C
Maximum Power | 23kW
Power Supply | 3-phase 380VAC, 50Hz, 30kVA
Weight | 500kg
Installation Dimensions (D×W×H) | 800×900×1200mm

III. Heating/Cooling Control Cabinet
Control Channels: 5+2 (5 for furnace, 2 spare)
Controllers: Eurotherm 3504 or Japanese import (7 per cabinet)
Dimensions: 800×1850×500mm (W×H×D)
Color: Light gray

IV. Control System
Core Functions:

  • Smart Regulators: Eurotherm 3504/Japanese import with PID auto-tuning, overheat alerts, thermocouple failure indication
  • Control Mode: Power/voltage regulation
  • Overheat Protection: Audio-visual alarm + instant power cutoff

V. Key Advantages
High Uniformity: ±5°C for precision sintering processes
Safety Design: Multi-level alarms (overheat/thermocouple failure) & interlock protection
Scalability: Spare control channels for future upgrades


Item pecifications Quantity Notes
Kiln Main Unit Primary heating system 1 set Core equipment for thermal process
Setter Plate Material: Corundum-Mullite 1 set High-temperature resistant carrier
  1. The equipment must be installed indoors, with an ambient temperature range of -10℃ to 45℃. The indoor environment must be free of flammable gases, corrosive gases, and vapors.
  2. The equipment requires a floor space of no less than 4 square meters, with a working area length of at least 2 meters, width of at least 2 meters, and height of no less than 3 meters. The foundation must be sturdy and level, and the furnace weighs approximately 400kg.
  3. The power supply for this furnace must be a three-phase five-wire AC power line, with a voltage of 380±10% V and a frequency of 50±2% Hz. This power line is dedicated, and high-power conversion equipment such as welding machines, electric furnaces, and metal-cutting machine tools should not be connected to this distribution.
  4. The equipment must be reliably grounded.

HBF105-14 Simple Operation Atmosphere Box Furnace High Uniformity Atmosphere Box FurnaceHBF105-14 Simple Operation Atmosphere Box Furnace High Uniformity Atmosphere Box FurnaceHBF105-14 Simple Operation Atmosphere Box Furnace High Uniformity Atmosphere Box FurnaceHBF105-14 Simple Operation Atmosphere Box Furnace High Uniformity Atmosphere Box FurnaceHBF105-14 Simple Operation Atmosphere Box Furnace High Uniformity Atmosphere Box Furnace
