Electric Chitherm MBF22-11N Medium-Temperature Atmosphere Box Furnace with Nitrogen/Air capability, designed for precision industrial heating applications up to 1100°C.

• Rated Temperature: 1000°C
• Maximum Temperature: 1100°C
• Effective Size: 330mm×200mm×330mm (W×H×D)
• Sagger Specification: 330mm×100mm×330mm (W×H×D)
• Loading Method: SiC roller rods in double-layer, longitudinal double-row arrangement
• Heating Element: Silicon carbide rod inserted in ceramic tube
• Temperature Control: ±1°C accuracy with PID self-tuning
• Furnace Temperature Uniformity: ±5°C
• Sintering Atmosphere: Nitrogen/Air with oxygen content better than 10ppm
• Maximum Heating Power: 12kW
• Heating Rate: ≤5°C/min

• Environment: 0-40°C, ≤80%RH, no corrosive gases
• Ventilation: Exhaust capacity >10m³/h
• Gas Source: High-purity nitrogen (99.999%) or clean compressed air
• Power: >16kVA, 3-phase 5-wire, 220/380V, 50Hz
• Installation Space: 2000×2000×3000mm (D×W×H)

Hefei Chitherm Equipment Co., Ltd. is a professional enterprise engaged in the research and development, design, manufacturing, sales, maintenance and service of high, medium and low temperature industrial furnaces and experimental furnaces. Our products include Bell Furnaces, Box Furnaces, Hot Air Dryer, Tube Furnaces, Vacuum Furnaces, Trolley Furnaces, and Rotary Furnaces. All of which are widely used in scientific research and experimentation in advanced ceramics, additive manufacturing, powder metallurgy, new energy and other fields. Suitable for the extrusion, sintering process of magnetic materials, honeycomb ceramics, alumina ceramics, zirconia ceramics, CIM/MIM, and positive and negative electrode materials of lithium batteries, as well as various other new materials such as pre-firing, extrusion, degreasing, firing, drying, co-firing, post-firing, soldering, curing, ceramic metallization, etc. We insist responsible attitude towards customers and provide high-quality products and services. It is precisely because of the support, understanding, and trust of our customers and friends that our intelligent equipment manufacturing capabilities continue to improve. We are willing to work with customers to support the rapid development of electronis and advance materials all over the world.
