F1300L 1300HP Diesel Mud Pump 5000 Psi High Pressure Mud Pumps
F1300L 1300HP Diesel Mud Pump 5000 Psi High Pressure Mud Pumps
F1300L 1300HP Diesel Mud Pump 5000 Psi High Pressure Mud Pumps
F1300L 1300HP Diesel Mud Pump 5000 Psi High Pressure Mud Pumps
F1300L 1300HP Diesel Mud Pump 5000 Psi High Pressure Mud Pumps
F1300L 1300HP Diesel Mud Pump 5000 Psi High Pressure Mud Pumps
Specifications
Brand Name :
Hebei Pantu
Model Number :
F1300L
Certification :
API 7K & ISO
Place of Origin :
China
MOQ :
1
Price :
10000USD~50000USD
Payment Terms :
L/C,T/T
Supply Ability :
20sets/month
Delivery Time :
45 days
Packaging Details :
3302mm*1671mm*1412mm(13ft*6.85ft*5.56ft)
Name :
1300 HP Drilling Mud Pump
Rated input Power : :
1300 HP
Stroke Per Minute: :
120 SPM
Stroke Length: :
184 mm (7 1/4")
Gear Ratio: :
4.206:1
Max. Working Pressure: :
34.5 MPa
Max. Working Pressure :
5000 psi
Driven :
Diesel Engine
Description

F1300L 1300 HP Drilling Mud Pump Diesel Engine Driven

Product Overview

  1. The frame is welded with steel plates. The pinion shaft bearing seats and the upper and bottom seats of the crankshaft is made of cast steel. There are necessary oil sump and oil pipeline systems in the frame, which are used for cooling and lubrication
  2. The crankshaft is made of cast alloy steel.
    The pinion shaft and the big herringbone gear are made of forged alloy steel with medium hardness gear surface.
  3. The crosshead is cast with nodular cast iron. The crosshead guides include the upper and the bottom guides. Gaskets may be added under the bottom guide to regulate the concentricity.
  4. The fluid cylinders are made of forged alloy steel. The cylinders include the suction and the discharge cylinders and they have assembled as L types the 12-P-160 mud pump of National Oil Wel. The cylinder surface is processed by chemical plating to increase their resistance to corrosion fluid end wearing parts are the same as the 12-P-160 mud pump and can be bought internationally.

Key Features

  1. Durable Construction – Fabricated with high-strength alloy steel for longer service life under harsh drilling conditions.
  2. High Pumping Efficiency – Optimized fluid end design ensures steady displacement and minimal pulsation.
  3. Flexible Power Options – Compatible with both electric motor and diesel engine drives.
  4. Easy Maintenance – Modular design allows quick replacement of fluid end parts, reducing downtime.
  5. Enhanced Lubrication System – Combination of splash and forced lubrication for extended bearing life.
  6. API & ISO Compliance – Designed and manufactured according to API Spec 7K and ISO 9001 standards.

Technical Specifications

Liner Size in 7 6 3/4
6 1/2
6 1/4
6
5 1/2
 5
Discharge Pressure Mpa
19.2
20.6
22.3
24.1
26.1
31.1
34.5
psi
2785
2988

3234

3495
3785
4510
5000
Stroke per Minute
(SPM)		 Power
KW(HP)
Displacement L/s(GPM)
130
1050
(1408)
49.17
(779.6)
45.74
(725.0)
42.41
(672.2)
39.22
(621.6)
36.14
(572.8)
30.36
(481.2)
25.10
(397.8)
120
*970
(1300)
45.41
(719.7)
41
(649.8)
39.15
(620.5)
36.20
(573.7)
33.36
(528.7)
28.03
(444.2)
23.17
(367.2)
110
889
(1192)
41.63
(659.8)
38.07
(603.4)
35.89
(568.8)
33.18
(525.9)
30.58
(484.7)
25.69
(407.1)
21.24
(336.6)
100
808
(1083)
37.84
(599.7)
35.18
(557.6)
32.63
(517.1)
30.17
(478.2)
27.8
(440.6)
23.36
(370.2)
19.31
(306.0)
90
727
(975)
34.06
(539.8)
31.67
(501.9)
29.36
(465.3)
27.15
(430.3)
25.02
(396.5)
21.02
(333.1)
13.38
(212.0)
50
404
(541)
18.92
(299.8)
17.59
(278.8)
16.31
(258.5)
15.08
(239.0)
13.9
(220.3)
11.68
(185.1)
9.65
(152.9)
1
8.08
(10.8)
0.3784
(6.00)
0.3518
(5.57)
0.3518
(5.57)
0.3263
(5.17)
0.278
(4.40)
0.2336
(3.70)
0.1931
(3.06)
--Performance data are calculated by 90% mechanical efficiency and 100% volumetric efficiency.　　　　　　　　
--The * present the recommendatory SPM and input power when the mud pump runs continuously.　　　　　　　　


F1300L Drilling Mud Pump Specification :

Rated Input Power: 970 kW (1300 HP)

Stroke Per Minute: 120 SPM
Gear Ratio: 4.206:1
Max. Working Pressure: 34.5 MPa (5000 psi)

cylinder Type: L
Max.Liner Size : 184 mm (7 1/4")
suction Inlet Flange: 304.8 mm (12") flange
Discharge Outlet Flange: 130.2 mm (5 1/8") flange,34.5 MPa (5000 psi)

Pinion Shaft Dia.×Extension Length : 215.9 mm×336 mm (8.5"×13.23")

Overall Dimension (L×W×H):4804×2414×1850 mm3(15.76×7.92×6.07 ft3)

Approx Weight: 22860 kg (50398 lb)

Applications

  1. Onshore and offshore oil drilling rigs
  2. Geothermal drilling projects
  3. Coalbed methane drilling
  4. Large-diameter water well drilling

Why Choose Our Mud Pump?

  1. Proven track record in Middle East, North America, Russia, and Africa oilfields.
  2. Global spare parts supply and after-sales service network.
