F Series Triplex Mud Pump Piston Horizontal 2200HP In Oilfield
F Series Triplex Mud Pump Piston Horizontal 2200HP In Oilfield
F Series Triplex Mud Pump Piston Horizontal 2200HP In Oilfield
F Series Triplex Mud Pump Piston Horizontal 2200HP In Oilfield
F Series Triplex Mud Pump Piston Horizontal 2200HP In Oilfield
F Series Triplex Mud Pump Piston Horizontal 2200HP In Oilfield
Specifications
Brand Name :
Hebei Pantu
Model Number :
QF2200
Certification :
API 7K & ISO
Place of Origin :
China
MOQ :
1
Price :
10000USD~50000USD
Payment Terms :
L/C,T/T
Supply Ability :
20sets/month
Delivery Time :
45 days
Packaging Details :
3302mm*1671mm*1412mm(13ft*6.85ft*5.56ft)
Name :
Triplex Piston Drilling Mud Pump
Rated input Power: :
1641 kW (2200 HP)
stroke Per Minutes :
110 SPM
Stroke Length: :
13"
Gear Ratio: :
3.969:1
Valve :
API #8
Max. Working Pressure :
7500 psi
Overall Dimension (L×W×H) :
16.62×8.75×7.01 ft3
Description

QF2200 Triplex Piston Drilling Mud Pump In Oilfield

Product Overview

  1. F2000 Triplex Piston Drilling Mud Pump is firm and compact in structure and small in size, with good functional performances, which can adapt to drilling technological requirements such as oilfield high pump pressure and large displacement, etc.
  2. The F series Triplex Piston Drilling Mud Pump can be maintained at a lower stroke rate for their long stroke, which effectively improves the feeding water performance of mud pumps and prolongs the service life of the fluid end.
  3. The suction stabilizer, with its advanced structure and reliable service, can achieve the best buffering effect. Power ends of the F series mud pumps adopt the reliable combination of forced lubrication and splash lubrication to increase the service life of power ends.

Key Features

  1. Durable Construction – Fabricated with high-strength alloy steel for longer service life under harsh drilling conditions.
  2. High Pumping Efficiency – Optimized fluid end design ensures steady displacement and minimal pulsation.
  3. Flexible Power Options – Compatible with both electric motor and diesel engine drives.
  4. Easy Maintenance – Modular design allows quick replacement of fluid end parts, reducing downtime.
  5. Enhanced Lubrication System – Combination of splash and forced lubrication for extended bearing life.
  6. API & ISO Compliance – Designed and manufactured according to API Spec 7K and ISO 9001 standards.

Technical Specifications

Liner Size mm
230
220
210
200
190
180
170
160
150
140
Discharge Pressure Mpa
19.5
21.7
23.5
25.8
28.7
31.9
35.8
40.4
46.0
51.7
psi
2823
3141
3402
3735

4155

4618
5183
5849
6660
7500
Stroke per Minute
(SPM)		 Power
KW(HP)
Displacement L/s(GPM)
110
1640
(2200)
75.5
69
62.9
57.1
51.5
46.2
41.2
36.5
32.1
28
100
1490
(2000)
68.6
62.7
57.2
51.9
46.8
42.0
37.5
33.2
29.2
25.5
90
1342
(1800)
61.8
56.5
51.5
46.7
42.1
37.8
33.7
29.9
26.3
22.9
80
1192
(1600)
54.9
50.2
45.7
41.5
37.5
33.6
30.0
26.5
23.3
20.3
50
745.5
(1000)
34.3
31.4
28.6
25.9
23.4
21.0
18.7
16.6
14.6
12.7
1
14.9
(20)
0.68
0.63
0.57
0.52
0.47
0.42
0.37
0.33
0.29
0.25
--Performance data are calculated by 90% mechanical efficiency and 100% volumetric efficiency.　　　　　　　　
--The * present the recommendatory SPM and input power when the mud pump runs continuously.　　　　　　　　


Triplex Piston Drilling Mud Pump Specification :

Rated input Power : 1641 kW(2200 HP)Stroke Per Minute : 110 SPM
Stroke Length: 330.2 mm (13")Gear Ratio: 3.969:1
Max. Working Pressure: 52 MPa (7500 psi)Valve: API#8
Max.Liner Size : 230 mm(9 1/20")
Suction Inlet Flange: 254 mm (10") flange
Discharge Outlet Flange: 130.2 mm (5 1/8") flange, 70 MPa (10000 psi)Overall Dimension (L×W×H):5065×2667×2137 mm3(16.62×8.75×7.01 ft3)Approx Weight: 28380 kg (62567 lb)

Applications

  1. Onshore and offshore oil drilling rigs
  2. Geothermal drilling projects
  3. Coalbed methane drilling
  4. Large-diameter water well drilling

Why Choose Our Mud Pump?

  1. Proven track record in Middle East, North America, Russia, and Africa oilfields.
  2. Global spare parts supply and after-sales service network.
