Dustproof Test Chamber
Dustproof Test Chamber
Dustproof Test Chamber
Dustproof Test Chamber
Dustproof Test Chamber
Dustproof Test Chamber
Specifications
Brand Name :
SPR-ing
Model Number :
JSD-5
Certification :
GB2423.1、 GB2423.2、 GJB150.3、GJB150.4、GB11158、GB10589
Place of Origin :
Shenzhen
MOQ :
1 piece
Price :
15000~50000 USD
Payment Terms :
T/T
Supply Ability :
20/month
Delivery Time :
1~3 weeks
Packaging Details :
Wooden carton
Nominal internal volume (L) :
330~2000
Temperature range :
-70~220℃
Heating speed :
3~6℃/min
Cooling speed :
2~3.5℃/min
Thermal compensation capability :
1500~3000W
Cooling method :
Air/water cooled (optional)
Power supply mode :
AC380V±10% 50Hz 3/N/PE
Maximum power :
15.5kw
Maximum current :
30A
Description
Dustproof Test Chamber
Product Characteristics

◆ Predicting the dust-resistant quality of industrial and electronic products by artificially simulating the dusty environment and climate
◆ The sand and dust particles are sprayed on the test sample through the sand and dust generator, sand blasting device and other equipment, and the sand and dust environment and test conditions are controlled by the circulating fan and filter device.
◆ The box is used to simulate the sand and dust environment, the sand blasting device and the circulating fan control the movement and circulation of the sand and dust particles, the filtering device can effectively filter the sand and dust particles, and the sample holder is used to place the test samples.

III. Main uses
◆ The sand and dust test chamber is used to test the sealing performance of the product shell, and is mainly used for the test of the two levels of IP5X and IP6X of the shell protection level. By simulating sand and dust weather, outdoor lamps, auto parts, outdoor cabinets, power meters and other products are tested.

Model

JSD-5/6X-125

JSD-5/6X-500

YXHP56X-1000L

YX-IP56X-1500L

Capacity(L)

125

500

1000

1500

Inner size

500x500x500mm 800x800x800mm 1000x1000x1000mm 1000x 1500×1000mm

Outer size

1450x 1720x1970mm

Power

1.0KW 1.5kw 1.5KW 2.0KW

Time setting range

0-999h adjustable

Temperature setting range

RT+10~70 ° C (specify when ordering)

Experimental dust

Talc powder/Alexander powder

Dust consumption

2-4kg/m3

Dust reduction method

Free powder spraying for dust reduction

vacuum degree

0-10.0kpa (adjustable)

Protector

Leakage protection, short circuit protection

supply voltage

220V
Areas of Application
  • Automotive industry - Vehicle and parts testing under extreme weather conditions to ensure reliability and durability of body, engine, and electronic systems.
  • Aerospace - Environmental adaptability testing for aircraft, satellites, and spacecraft under extreme conditions including temperature variations and low atmospheric pressure.
  • Electronic and electrical equipment - Reliability testing for household appliances, industrial equipment, and communication devices in high humidity, temperature changes, and salt fog environments.
  • Construction and engineering materials - Weather resistance testing for concrete, steel, glass, and other building materials under temperature and humidity variations.
  • Military Industry and Defense - Operational performance testing of military equipment under extreme weather conditions and battlefield simulations.
  • Energy and Power Industry - Performance testing of solar cells and wind power equipment under extreme weather conditions.
  • Medical devices - Reliability testing of medical equipment and biomaterials under temperature and humidity variations.
  • Food and pharmaceutical industry - Stability testing of packaging materials and shelf life evaluation under various storage conditions.
  • Marine engineering - Corrosion resistance testing for offshore platforms, hulls, and submarine cables in simulated marine environments.
  • Scientific research - Development of new anti-aging materials and environmental impact studies.
Compliance Standards
GB2423.1 GB2423.2 GJB150.3 GJB150.4 GB11158 GB10589
