Three Comprehensive Environmental Test Chamber
Three Comprehensive Environmental Test Chamber
Three Comprehensive Environmental Test Chamber
Three Comprehensive Environmental Test Chamber
Three Comprehensive Environmental Test Chamber
Three Comprehensive Environmental Test Chamber
Specifications
Brand Name :
SPR-ing
Model Number :
JT/JC 490C（L） -10ES
Certification :
GB2423.1、 GB2423.2、 GJB150.3、GJB150.4、GB11158、GB10589
Place of Origin :
Shenzhen
MOQ :
1 piece
Price :
15000~50000 USD
Payment Terms :
T/T
Supply Ability :
20/month
Delivery Time :
1~3 weeks
Packaging Details :
Wooden carton
Nominal internal volume (L) :
330~2000
Temperature range :
-70~220℃
Heating speed :
3~6℃/min
Cooling speed :
2~3.5℃/min
Thermal compensation capability :
1500~3000W
Cooling method :
Air/water cooled (optional)
Power supply mode :
AC380V±10% 50Hz 3/N/PE
Maximum power :
15.5kw
Maximum current :
30A
Description
Three Comprehensive Environmental Test Chamber
Product characteristics
◆ Advanced air duct design, apply CFD flow field simulation technology to adjust and optimize the air flow field inside the environmental test chamber to ensure the temperature uniformity and fluctuation of the environmental test chamber, and effectively control the frosting phenomenon of the evaporator.
◆ Excellent energy-saving and consumption-reducing technology. The control system adopts PWM cold control mode for heating without refrigeration and refrigeration without heating, which can save energy by more than 40% under constant operating conditions.
◆ Diversified structural forms, three integrated products can provide three structural forms of self-lifting, scissors-fork hydraulic table and gantry (mainly for large three-integrated) according to the user's on-site conditions and the volume of the box.
Three Comprehensive Environmental Test Chamber
Three Comprehensive Environmental Test Chamber
Air Flow Field Diagram in the Box

Unique Air Circulation System and Software Control System

Product Characteristics
  • 10-inch color capacitive touch screen for enhanced user experience and convenient operation
  • Autonomous intelligent control logic system for precise temperature control with wide range capability
  • SUS304 mirror stainless steel inner container with excellent corrosion resistance and easy cleaning
  • Advanced energy-saving design with intelligent control system and special air circulation
Technical SpecificationsTest Method & Compliance

All performance indexes are measured under no-load conditions at ambient temperature of 20±2℃ (according to GB/T 5170.2-2017). Temperature and humidity performance test follows standard IEC 60068 3-5, with sensor placed at the air outlet of the air handling unit.

Complies with: GB2423.1, GB2423.2, GJB150.3, GJB150.4, GB11158, GB10589
