Small Size Electronic Latching Relay , Double Coil 440VAC Electromechanical Relay
Small Size Electronic Latching Relay , Double Coil 440VAC Electromechanical Relay
Specifications
Brand Name :
WSD
Model Number :
WSD-508HC-100A
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
20000/day
Delivery Time :
14-21days
Packaging Details :
Cartons / Pallets
Contact Form :
2B
Contact Material :
AgSnO2
Operate Time :
25ms Max.
Release Time :
25ms Max.
Rated Load(Resistive) :
100A 250VAC
Outline Dimension :
58X40X21 (mm)
Description

Double coil latching relay 100A contact switching capability 440VAC

◇ 100A contact switching capability

  • ◇ Only impulse excitation needed, both for single and double coil.
  • ◇ Low power consumption, small in size
  • ◇ Custom assemblies available with flexible wire and/or copper straps, and/or with integrated shunt
  • ◇ 4KV dielectric strength between coil and contacts
  • ◇ RoHS compliant
  • ◇ Outline dimensions: (58 x 40 x 21) mm
Coil Data (20℃)
Coil Voltage Coil Resistance (Ω) Coil Power (W) Operating Voltage Releasing Voltage Allowing Voltage Pulse Duration
(VDC) Single Double Single Double (VDC) (VDC) (VDC) (ms)
6 16 8/8 2.25 4.5 ≤4.5 ≤4.5 9 ≥90
9 36 18/18 ≤6.75 ≤6.75 13.5
12 64 32/32 ≤9 ≤9 18
24 256 128/128 ≤18 ≤18 36
Contact Data Characteristics
Contact Form 2B Operate Time 25ms Max.
Contact Material AgSnO2 Release Time 25ms Max.
Contact Resistance Max.1.0mΩ (1A 6VDC) Insulation Resistance (500VDC) 500MΩ Min.
Dielectric Strength (50/60Hz,1Min) Contact to Coil 4000VAC
Rated Load(Resistive) 100A 250VAC Across Open Contacts 2000VAC
Max.Switching Voltage 440VAC Contact to contact
Max.Switching Current 100A Surge Voltage (1.2/50μs) Contact to Coil 20KVAC
Max.Switching Power 25000VA / 2800W
Service Life Mechnical Endurance 1×105OPS Dielectric Creepage 8mm
Electrical Endurance 6×103OPS Unit Weight About 95g
Max.Short-Circut Current 1500A/10ms Outline Dimension (without connecting parts) 58X40X21 (mm)
Environmental Data
Ambient Temperature -40℃～+70℃ Relative Humidity 5%-85% RH
Vibration 10-55Hz 1.5mm Shock 98m/s2
Product tags

coil latching relay

,

single coil latching relay

,

two coil latching relay
