1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
1400C Low Vacuum Degree Furnace Heat Chamber 380V 50HZ Customized
Specifications
Brand Name :
Achemetal
Model Number :
ASTM
Certification :
ISO14001
Place of Origin :
Henan, China
MOQ :
Ten units every six months
Price :
$3,000.00-$10,000.00
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5000 Kilogram/Kilograms per Month
Delivery Time :
60-90 work days
Packaging Details :
Customization
Key Selling Points :
Flexible Manufacturing
Power (kW) :
160
Voltage :
380V 50HZ
Showroom Location :
None
Machinery Test Report :
Provided
Applicable Industries :
Manufacturing Plant
Dimension(L*W*H) :
customized
Marketing Type :
Hot product
Description

Product Detail

 Specification Furnace Heat Chamber
Heating chamber for vacuum annealing furnace components
Valid zone Maximum temperature (℃) Heating power (kw) Ultimate vacuum (Pa) Gas cooling pressure (bar)
450x300x300 1320 40 5x10-3or4x10-1 2
600x400x400 1320 80 5x10-3or4x10-1 2
750x500x500 1320 120 5x10-3or4x10-1 2
900x600x600 1320 150 5x10-3or4x10-1 2
1200X600X600 1320 200 5x10-3or4x10-1 2
1500x800x800 1320 360 5x10-3or4x10-1 2

The heating chamber can adopt graphite tube heating and multi-layer graphite felt or graphite hard felt insulation structure;

For products with high requirements or special materials brazing, the heating chamber can also adopt molybdenum belt heating and molybdenum sheet and stainless steel sheet composite insulation structure;

The size of valid zone can be customized according to customer requirements;

Computer control system;
Product description: Mainly used for bright annealing of high alloy steel, magnetic materials, stainless steel, titanium alloy, nonferrous metals and other materials.

features

1. Temperature control accuracy: ±1°C, furnace temperature uniformity: ±2°C (depending on the size of the heating chamber).

2. Microcomputer control, multi-channel control, realizes multi-channel simultaneous heating, heat preservation and cooling, easy to operate. Programmable, PID self-tuning, automatic heating, automatic heating, automatic cooling, no need to be on duty; can be equipped with computer communication through the computer to operate the electric furnace (starting the electric furnace, stopping the electric furnace, pausing the heating, setting the heating curve, heating curve storage, history curve Wait)

3. Fast heating (the heating rate can be adjusted from 1°C/min to 20°C/min).

4. Imported refractory material, good thermal insulation performance, high temperature resistance, resistance to rapid cooling and rapid heating.

5. Electric or manual hydraulic lifting of furnace door.

Furnace can be customized according to customer needs
